(4) Pull the bulb from the socket.
Installation
(1) Push the bulb into the socket.
(2) Install the socket into the lamp.
(3) Place the license plate lamp in position in the
rear bumper fascia.
(4) Install the screws attaching the rear license
plate lamp to the rear bumper fascia.
CHMSL LAMP BULB
Removal
(1) Release the deck lid latch and open deck lid.
(2) Remove the trunk lid cover.
(3) Grasp the chmsl lamp socket and rotate coun-
terclockwise. Separate the bulb lamp socket from the
lamp assembly (Fig. 20).
(4) Remove the bulb from the socket.
Installation
(1) Install the bulb into the socket.
(2) Install the socket into the lamp assembly.
(3) Install the deck lid cover.
Fig. 20 CHMSL
1 – CHMSL BULB SOCKET
2 – CHMSL BULB
3 – CHMSL
4 – CHMSL FASTENER
5 – CHMSL FASTENER
8L - 14 LAMPS LH
REMOVAL AND INSTALLATION (Continued)
2000 LHS, 300M, CONCORDE AND INTREPID
