8W-30 FUEL/IGNITION SYSTEM
Component Page
A/C Compressor Clutch Relay .......... 8W-30-16
A/C Pressure Transducer ........... 8W-30-12, 13
Automatic Shut Down Relay . 8W-30-2, 3, 4, 6, 10, 11
Body Control Module ............... 8W-30-8, 19
Brake Lamp Switch ............... 8W-30-14, 15
Camshaft Position Sensor ........ 8W-30-7, 12, 20
Capacitor No. 1 .................... 8W-30-4, 6
Capacitor No. 2 .................... 8W-30-4, 6
Clockspring No. 1 ................. 8W-30-9, 14
Coil On Plug No. 1 ................. 8W-30-4, 6
Coil On Plug No. 2 ................. 8W-30-4, 6
Coil On Plug No. 3 ................. 8W-30-4, 6
Coil On Plug No. 4 ................. 8W-30-4, 6
Coil On Plug No. 5 ................. 8W-30-4, 6
Coil On Plug No. 6 ................. 8W-30-4, 6
Crankshaft Position Sensor .......... 8W-30-7, 20
Data Link Connector ................. 8W-30-19
EGR Solenoid ...................... 8W-30-18
Engine Coolant Temperature Sensor ..... 8W-30-9
Engine Starter Motor Relay ........... 8W-30-14
Evap/Purge Solenoid .............. 8W-30-12, 20
Fuel Injector No. 1 ................. 8W-30-3, 5
Fuel Injector No. 2 ................. 8W-30-3, 5
Fuel Injector No. 3 ................. 8W-30-3, 5
Fuel Injector No. 4 ................. 8W-30-3, 5
Fuel Injector No. 5 ................. 8W-30-3, 5
Fuel Injector No. 6 ................. 8W-30-3, 5
Fuel Pump Module ................... 8W-30-8
Fuel Pump Relay .................... 8W-30-8
Fuse 1 (JB) ........................ 8W-30-19
Fuse 13 (JB) ........................ 8W-30-8
Fuse 14 (JB) ....................... 8W-30-15
Fuse 19 (JB) ....................... 8W-30-19
Fuse 21 (JB) ....................... 8W-30-16
Fuse G (PDC) ....................... 8W-30-8
Fuse N (PDC) ....................... 8W-30-2
Fuse S (PDC) .................... 8W-30-3, 4, 6
Component Page
Fuse T (PDC) ............... 8W-30-2, 10, 11, 18
G102 .............................. 8W-30-2
G103 .......................... 8W-30-10, 11
G104 .......................... 8W-30-10, 11
G200 ............................. 8W-30-19
G201 ............................. 8W-30-19
G301 .............................. 8W-30-8
G303 .............................. 8W-30-8
Generator .......................... 8W-30-2
High Speed Radiator Fan Relay ........ 8W-30-16
Idle Air Control Motor ................ 8W-30-17
Instrument Cluster .................. 8W-30-15
Intake Air Temperature Sensor ......... 8W-30-12
Intake Air Temperature/Manifold Absolute
Pressure Sensor .................. 8W-30-13
Junction Block .............. 8W-30-8, 15, 16, 19
Knock Sensor ................... 8W-30-7, 9, 12
Leak Detection Pump ................ 8W-30-16
Low Speed Radiator Fan Relay ......... 8W-30-16
Manifold Absolute Pressure Sensor ...... 8W-30-12
Manifold Tuning Valve ................ 8W-30-6
Oxygen Sensor 1/1 Right Bank Up ...... 8W-30-10
Oxygen Sensor 1/2 Right Bank Down .... 8W-30-11
Oxygen Sensor 2/1 Left Bank Up ....... 8W-30-10
Oxygen Sensor 2/2 Left Bank Down ..... 8W-30-11
Power Distribution Center . . . 8W-30-2, 3, 4, 6, 8, 10,
11, 14, 18
Power Steering Pressure Switch ......... 8W-30-9
Powertrain Control Module . 8W-30-2, 3, 4, 5, 6, 7, 8,
9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20
Shift Interlock Solenoid .............. 8W-30-15
Short Runner Valve Solenoid .......... 8W-30-18
Throttle Position Sensor ............... 8W-30-9
Transmission Control Module ....... 8W-30-14, 19
Transmission Range Sensor ........... 8W-30-14
Vehicle Speed Control Servo ........... 8W-30-14
Vehicle Speed Control/Horn Switch ...... 8W-30-14
LH 8W - 30 FUEL/IGNITION SYSTEM 8W - 30 - 1
