BULB APPLICATION
TABLE OF CONTENTS
page page
SPECIFICATIONS
DIMMER CONTROLLED INTERIOR LAMPS .....25
EXTERIOR LAMP BULBS...................25
INDICATOR LAMPS .......................26
NON DIMMER CONTROLLED INTERIOR
LAMPS ...............................26
SPECIFICATIONS
DIMMER CONTROLLED INTERIOR LAMPS
Service procedures for most of the lamps in the
instrument panel, Instrument cluster and switches
are located in Group 8E, Instrument Panel and
Gauges. Some components have lamps that can only
be serviced by a Authorized Service Center (ASC)
after the component is removed from the vehicle.
Contact local dealer for location of nearest ASC.
LAMP LOCATION BULB NUMBER
A/C Heater Control ...................... 330
Ash Receiver ........................... 161
Headlamp Switch ................... 4798351
Instrument Cluster ................... PC194
Radio ................................ ASC
Analog Clock ......................... A9625
EXTERIOR LAMP BULBS
CAUTION: Do not use bulbs that have a higher can-
dle power than the bulb listed in the Bulb Applica-
tion Table. Damage to lamp can result.
CAUTION: Do not touch halogen bulbs with fingers
or other oily surfaces. Bulb life will be reduced.
EXTERIOR LAMP BULB CHART
LAMP NAME BULB NUMBER
Back up Concorde/LHS 921
Back up Intrepid/300M 3157K
Center High Mounted Stop - Two
Bulbs
Concorde/LHS 921
Center High Mounted Stop - Two
Bulbs
Intrepid 912
Center High Mounted Stop - One
Bulb
300M 921
Front Parking/Turn Signal LHS 3157 K
Front Parking/Turn Signal/Side
Marker
Concorde/300M 3157 KNA
Front Parking/Turn Signal/Side
Marker
Intrepid 3157 KNA
Front Side Marker LHS 168
Fog lamps Intrepid H-3 (35 watt)
300M H-3 (55 watt)
LHS 9040 (40 Watt)
LH LAMPS 8L - 25
