Chrysler 2000 LHS User Manual

POWER SEAT SYSTEMS
TABLE OF CONTENTS
page page
POWER SEATS ............................ 1 MEMORY SEATS........................... 5
POWER SEATS
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION
POWER SEAT SYSTEM.....................1
POSITION SENSING POWER SEAT
POTENTIOMETERS ......................1
POWER SEAT SWITCH .....................1
DIAGNOSIS AND TESTING
DIAGNOSTIC PROCEDURE..................2
CIRCUIT BREAKER ........................2
POWER SEAT SWITCH DIAGNOSTIC TEST .....2
MOTOR TESTS ...........................2
SWITCH TEST ............................3
VOLTAGE................................3
REMOVAL AND INSTALLATION
SEAT ASSEMBLY..........................4
SEAT ADJUSTER..........................4
SEAT SWITCH ............................4
DESCRIPTION AND OPERATION
POWER SEAT SYSTEM
DESCRIPTION
Power seats can be adjusted in 8 different direc-
tions:
• Up or down
• Forward or back
• Tilt forward or rearward
• Recliner up or down
OPERATION
Two single armature permanent magnet reversible
motors are coupled through cables to worm gear box
assemblies. They are located in the seat tracks and
upper supports. The two single gear motor assem-
blies attach to the seat tracks provide the various
seat movements.
The electrical circuit is protected by a 20 amp cir-
cuit breaker located on the Junction Block and a 40
amp fuse in the Power Distribution Center.
POSITION SENSING POWER SEAT
POTENTIOMETERS
DESCRIPTION
A potentiometer is mounted to each seat motor to
provide a sense voltage to the MHSMM that will
indicate where the actual seat position is.
OPERATION
This sense voltage is derived from a 5-volt source
provided by the module to the potentiometer. The
MHSMM reads this sense voltage and stores it if
required.
POWER SEAT SWITCH
DESCRIPTION
The seat switch assembly is mounted outboard in
the seat cushion side cover.
OPERATION
Activating any seat switch will move the seat in
the corresponding direction. The MHSMM will drive
a maximum of two motors at a time in a given direc-
tion. If conflicting directions are requested, the prior-
ities for responses are as follows:
LH POWER SEAT SYSTEMS 8R - 1
