Connector
Name/Number
Color Location Fig.
C110 (2.7L) Rear of Engine N/S
C111 GY Near Left
Headlamp
3
C112 GY Near Left
Headlamp
2
C113 GY Under Left
Headlamp
N/S
C114 Under Left
Headlamp
N/S
C200 BL Left Side
Instrument
Panel
8, 11
C201 WT Right Side
Instrument
Panel
9, 10
C202 WT Lower Center
of Instrument
Panel
9
C203 WT Lower Center
of Instrument
Panel
9
C204 WT At Headliner N/S
C300 Left Cowl 11
C301 Left Cowl 11
C302 Right Cowl 10,
15
C303 Right Cowl 10,
15
C304 Left B Pillar 11
C305 Right B Pillar 10
C306 YL Under
Passenger
Seat
10
C307 BK Under
passenger
Seat
11
C308 NAT Under Rear
Seat
10
C309 Under Driver
Seat
N/S
C310 Under
Passenger
Seat
N/S
C311 Left Trunk Area 14
C312 Left Trunk Area 13
C313 Right Trunk
Area
13
Connector
Name/Number
Color Location Fig.
C314 Left Trunk Area 13
C316 Left B Pillar 11
C317 Right B Pillar 10
C318 NAT Under
Passenger
Seat
10
C319 NAT Under Drivers
Seat
11
C321
(300M)
Deck Lid 14
Camshaft
Position Sensor
BK Front of Engine 5, 6
Capacitor #1
(2.7L)
BK Rear of Engine N/S
Capacitor #2
(2.7L)
BK Rear of Engine N/S
Center High
Mounted Stop
Lamp
At Lamp N/S
Center Instrument
Panel Speaker
BK At Speaker 9
Cigar Lighter RD Lower Center
of Instrument
Panel
9
Clockspring No. 1 NAT Rear of
Clockspring
8
Clockspring No. 2 YL Rear of
Clockspring
8
Coil On Plug No.
1
BK At Plug 5, 6
Coil On Plug No.
2
BK At Plug 5, 6
Coil On Plug No.
3
BK At Plug 5, 6
Coil On Plug No.
4
BK At Plug 5, 6
Coil On Plug No.
5
BK At Plug 5, 6
Coil On Plug No.
6
BK At Plug 5, 6
Combination
Flasher
BK Left Side
Instrument
Panel
8, 11
Controller
Anti-Lock Brake
BK Left Fender
Side Shield
3
Crankshaft
Position Sensor
BK Rear of Cyl
Block
5, 6
8W - 90 - 2 8W - 90 CONNECTOR/GROUND LOCATIONS LH
DESCRIPTION AND OPERATION (Continued)
