The bootstrap loader UM0404

304/564 DocID13284 Rev 2

Figure 124. ST10F276x new standard bootstrap loader program flow

START

Falling-edge on

UART0 RxD?

Falling-edge on

CAN1 RxD?

Start Timer PT0

UART RxD = 0?

CAN1 RxD = 1?

PT0 > 20?

Count = 1

CAN RxD = 0?

CAN1 RxD = 1?

Count += 1

Count = 5?

Stop Timer PT0

Initialize CAN

Address = FA40h

Stop Timer PT0

Message Received?

[Address] = MO15_data0

Address = Address + 1

Address = FAC0h?

Glitch on CAN1 RxD

Clear Timer PT0

Start Timer T6

UART0 RxD = 1?

Stop Timer T6

Initialize UART

Send Acknowledge

Address = FA40h

Byte Received?

[Address] = S0RBUF

Address = Address + 1

Address = FA60h?

Ye s

Jump to Address FA40h

UART BOOT

CAN BOOT

UART BOOT
