DocID13284 Rev 2 485/564

UM0404 System reset

Figure 200. SW / WDT unidirectional RESET (EA = 1)

P0[7:2] not transparent

P0[12:8]

transparent

not t.

P0[1:0]

not t.

not transparent

RST

1024 TCL

RSTOUT

RSTIN

IBUS-CS

7 TCL

P0[15:13] not transparent

FLARST

≤ 1 ms

(Internal)

≤ 2 TCL
