UM0404 System reset
23.9 Reset summary
A summary of the different reset events is reported in the table below.
Table 64. Reset events summary
Event
RPD
EA
Bidir
Synch.
asynch.
RSTIN WDTCON flags
min max
PONR
LHWR
SHWR
SWR
WDTR
Power-on reset
0 0 N Asynch.
1 ms (VREG)
1.2 ms (Reson. + PLL)
10.2 ms (Crystal +
PLL)
- 11110
0 1 N Asynch. 1ms (VREG) - 1 1 1 1 0
1 x x Forbidden
x x Y Not applicable
Hardware reset
(asynchronous)
0 0 N Asynch. 500ns - 0 1 1 1 0
0 1 N Asynch. 500ns - 0 1 1 1 0
0 0 Y Asynch. 500ns - 0 1 1 1 0
0 1 Y Asynch. 500ns - 0 1 1 1 0
Short hardware
reset
(synchronous)
(1)
1 0 N Synch.
max (4 TCL, 500ns)
1032 + 12 TCL +
max(4 TCL, 500ns)
00110
1 1 N Synch.
max (4 TCL, 500ns)
1032 + 12 TCL +
max(4 TCL, 500ns)
00110
1 0 Y Synch.
max (4 TCL, 500ns)
1032 + 12 TCL +
max(4 TCL, 500ns)
00110
Activated by internal logic for 1024 TCL
1 1 Y Synch.
max (4 TCL, 500ns)
1032 + 12 TCL +
max(4 TCL, 500ns)
00110
Activated by internal logic for 1024 TCL
Long hardware
reset
(synchronous)
1 0 N Synch.
1032 + 12 TCL +
max(4 TCL, 500ns)
-
01110
1 1 N Synch.
1032 + 12 TCL +
max(4 TCL, 500ns)
-
01110
1 0 Y Synch.
1032 + 12 TCL +
max(4 TCL, 500ns)
-
01110
Activated by internal logic only for 1024 TCL
1 1 Y Synch.
1032 + 12 TCL +
max(4 TCL, 500ns)
-
01110
Activated by internal logic only for 1024 TCL
