UM0404 Register set
26 Register set
This section summarizes all registers implemented in the ST10F276, and explains the
description format used in the sections describing the function and layout of the SFRs.
For easy reference the registers (except for GPRs) are ordered in two ways:
• Ordered by register name, to find the location of a specific register.
• Ordered by address, to check which register a given address references.
26.1 Register description format
Along the document, the function and the layout of the different registers is described in a
specific format. The examples below explain this format.
A word register looks like this:
REG_NAME (A16h / A8h) SFR/ESFR/XBUS Reset Value: ****h
A byte register looks like this:
REG_NAME (A16h / A8h) SFR/ESFR/XBUS Reset Value: - - **h
Elements:
1514131211109876543210
-----
wr
only
hw
bit
rd
only
std bit
hw
bit
bit field bit field
W RW R RW RW RW RW
Bit Function
bit(field) name
Explanation of bit(field) name
Description of the functions controlled by this bit(field).
1514131211109876543210
--------std bit
hw
bit
bit field bit field
RW RW RW RW
REG_NAME Name of this register
A16h / A8h Long 16-bit address / Short 8-bit address
SFR/ESFR/XBUS Register space (SFR, ESFR or XBUS Register)
(* *) * * Register contents after reset
0/1: defined
x: undefined (undefined (’x’) after Power-On)
U: unchanged
hw bit bits that are set/cleared by hardware are written in bold
- bits that are not implemented or reserved: never write to these bits
