26.3 Special function registers ordered by name
The following table lists all SFRs which are implemented in the ST10F276 in alphabetical
order.
Bit-addressable SFRs are marked with the letter “b” in column “Name”.
SFRs within the Extended SFR-Space (ESFRs) are marked with the letter “E” in column
“Physical Address”.
RH3 (CP) + 7 F7h CPU General Purpose (byte) Register RH3 UUh
RL4 (CP) + 8 F8h CPU General Purpose (byte) Register RL4 UUh
RH4 (CP) + 9 F9h CPU General Purpose (byte) Register RH4 UUh
RL5 (CP) + 10 FAh CPU General Purpose (byte) Register RL5 UUh
RH5 (CP) + 11 FBh CPU General Purpose (byte) Register RH5 UUh
RL6 (CP) + 12 FCh CPU General Purpose (byte) Register RL6 UUh
RH6 (CP) + 13 FDh CPU General Purpose (byte) Register RH6 UUh
RL7 (CP) + 14 FEh CPU General Purpose (byte) Register RL7 UUh
RH7 (CP) + 15 FFh CPU General Purpose (byte) Register RH7 UUh
Table 69. General purpose registers (GPRs) bit wise addressing (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
Table 70. Special function registers ordered by name
Name
Physical
address
8-bit
address
Description
Reset
value
ADCIC b FF98h CCh A/D Converter end of Conversion Interrupt Control Reg. - - 00h
ADCON b FFA0h D0h A/D Converter Control Register 0000h
ADDAT FEA0h 50h A/D Converter Result Register 0000h
ADDAT2 F0A0h E 50h A/D Converter 2 Result Register 0000h
ADDRSEL1 FE18h 0Ch Address Select Register 1 0000h
ADDRSEL2 FE1Ah 0Dh Address Select Register 2 0000h
ADDRSEL3 FE1Ch 0Eh Address Select Register 3 0000h
ADDRSEL4 FE1Eh 0Fh Address Select Register 4 0000h
ADEIC b FF9Ah CDh A/D Converter Overrun Error Interrupt Control Register - - 00h
BUSCON0 b FF0Ch 86h Bus Configuration Register 0 0xx0h
1)
BUSCON1 b FF14h 8Ah Bus Configuration Register 1 0000h
BUSCON2 b FF16h 8Bh Bus Configuration Register 2 0000h
BUSCON3 b FF18h 8Ch Bus Configuration Register 3 0000h
BUSCON4 b FF1Ah 8Dh Bus Configuration Register 4 0000h
CAPREL FE4Ah 25h GPT2 Capture/Reload Register 0000h
