UM0404 Register set
26.7 Flash registers ordered by name
The following table lists all Flash Control Registers which are implemented in the ST10F276
ordered by their name. Note that as they are physically mapped on the X-Bus, these
registers are not bit-addressable.
26.8 Flash registers ordered by address
The following table lists all Flash Control Registers which are implemented in the ST10F276
ordered by their physical address. Note that as they are physically mapped on the X-Bus,
these registers are not bit-addressable.
Table 74. Flash registers ordered by name
Name Physical address Description
Reset
value
FARH 0x000E 0012 Flash Address Register High 0000h
FARL 0x000E 0010 Flash Address Register Low 0000h
FCR0H 0x000E 0002 Flash Control Register 0 - High 0000h
FCR0L 0x000E 0000 Flash Control Register 0 - Low 0000h
FCR1H 0x000E 0006 Flash Control Register 1 - High 0000h
FCR1L 0x000E 0004 Flash Control Register 1 - Low 0000h
FDR0H 0x000E 000A Flash Data Register 0 - High FFFFh
FDR0L 0x000E 0008 Flash Data Register 0 - Low FFFFh
FDR1H 0x000E 000E Flash Data Register 1 - High FFFFh
FDR1L 0x000E 000C Flash Data Register 1 - Low FFFFh
FER 0x000E 0014 Flash Error Register 0000h
FNVAPR0 0x000E DFB8 Flash Non Volatile Access Protection Reg. 0 ACFFh
FNVAPR1H 0x000E DFBE Flash Non Volatile Access Protection Reg. 1 - High FFFFh
FNVAPR1L 0x000E DFBC Flash Non Volatile Access Protection Reg. 1 - Low FFFFh
FNVWPIRH 0x000E DFB6 Flash Non Volatile Protection I Reg. High FFFFh
FNVWPIRL 0x000E DFB4 Flash Non Volatile Protection I Reg. Low FFFFh
FNVWPXRH 0x000E DFB2 Flash Non Volatile Protection X Reg. High FFFFh
FNVWPXRL 0x000E DFB0 Flash Non Volatile Protection X Reg. Low FFFFh
XFICR 0x000E E000 XFlash Interface Control Register 000Fh
Table 75. Flash registers ordered by address
Name Physical address Description
Reset
value
FCR0L 0x000E 0000 Flash Control Register 0 - Low 0000h
FCR0H 0x000E 0002 Flash Control Register 0 - High 0000h
FCR1L 0x000E 0004 Flash Control Register 1 - Low 0000h
