System reset UM0404

488/564 DocID13284 Rev 2

Figure 202. SW / WDT bidirectional RESET(EA = 1)

P0[15:13] not transparent

RSTF

P0[12:8]

transparent

not t.

P0[1:0]

not t.

not transparent

RST

1024 TCL

RSTOUT

(After Filter)

RSTIN

≤

500 ns

≥

50 ns

≤

500 ns

≥

50 ns

IBUS-CS

7 TCL

FLARST

≤

1 ms

≤

2 TCL

(Internal)

P0[7:2] not transparent
