Register set UM0404
524/564 DocID13284 Rev 2
Note: 1 The BUSCON0 reset value is: 0000 0xx0 xx00 0000b.
2 The system configuration is selected during reset: in particular, the SYSCON reset value is
0000 0xx0 x000 0000b.
3 Reset Value depends on different triggered reset event.
4 The XPnIC Interrupt Control Registers control interrupt requests from integrated X-Bus
peripherals. Some software controlled interrupt requests may be generated by setting the
XPnIR bits (of XPnIC register) of the unused X-Peripheral nodes.
26.4 Special function registers ordered by address
The following table lists all SFRs which are implemented in the ST10F276 ordered by their
physical address. Bit-addressable SFRs are marked with the letter “b” in column “Name”.
SFRs within the Extended SFR-Space (ESFRs) are marked with the letter “E” in column
“Physical Address”. Registers within on-chip X-Peripherals (CAN) are marked with the letter
“X” in column “Physical Address”.
WDT FEAEh 57h Watchdog Timer Register (read only) 0000h
WDTCON b FFAEh D7h Watchdog Timer Control Register 00xxh
3)
XADRS3 F01Ch E 0Eh XPER Address Select Register 3 800Bh
XP0IC b F186h E C3h See Section 5.7: X-peripheral interrupt - - 00h
4)
XP1IC b F18Eh E C7h See Section 5.7: X-peripheral interrupt - - 00h
4)
XP2IC b F196h E CBh See Section 5.7: X-peripheral interrupt - - 00h
4)
XP3IC b F19Eh E CFh See Section 5.7: X-peripheral interrupt - - 00h
4)
XPERCON F024h E 12h XPER Configuration Register - - 05h
ZEROS b FF1Ch 8Eh Constant Value 0’s Register (read only) 0000h
Table 70. Special function registers ordered by name (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
Table 71. Special function registers ordered by address
Name
Physical
address
8-bit
address
Description
Reset
value
QX0 F000h E 00h MAC Unit Offset Register X0 0000h
QX1 F002h E 01h MAC Unit Offset Register X1 0000h
QR0 F004h E 02h MAC Unit Offset Register R0 0000h
QR1 F006h E 03h MAC Unit Offset Register R1 0000h
XADRS3 F01Ch E 0Eh XPER Address Select Register 3 800Bh
XPERCON F024h E 12h XPER Configuration Register - - 05h
PT0 F030h E 18h PWM Module Up/Down Counter 0 0000h
PT1 F032h E 19h PWM Module Up/Down Counter 1 0000h
PT2 F034h E 1Ah PWM Module Up/Down Counter 2 0000h
