UM0404 Register set
PT3 F036h E 1Bh PWM Module Up/Down Counter 3 0000h
PP0 F038h E 1Ch PWM Module Period Register 0 0000h
PP1 F03Ah E 1Dh PWM Module Period Register 1 0000h
PP2 F03Ch E 1Eh PWM Module Period Register 2 0000h
PP3 F03Eh E 1Fh PWM Module Period Register 3 0000h
T7 F050h E 28h CAPCOM Timer 7 Register 0000h
T8 F052h E 29h CAPCOM Timer 8 Register 0000h
T7REL F054h E 2Ah CAPCOM Timer 7 Reload Register 0000h
T8REL F056h E 2Bh CAPCOM Timer 8 Reload Register 0000h
IDPROG F078h E 3Ch Programming Voltage Identifier Register 0040h
IDMEM F07Ah E 3Dh On-chip Memory Identifier Register 30D0h
IDCHIP F07Ch E 3Eh Device Identifier Register (n is the device revision) 114nh
IDMANUF F07Eh E 3Fh Manufacturer Identifier Register 0403h
ADDAT2 F0A0h E 50h A/D Converter 2 Result Register 0000h
SSCTB F0B0h E 58h SSC Transmit Buffer (write only) 0000h
SSCRB F0B2h E 59h SSC Receive Buffer (read only) xxxxh
SSCBR F0B4h E 5Ah SSC Baud rate Register 0000h
DP0Lb F100h E 80h P0L Direction Control Register - - 00h
DP0Hb F102h E 81h P0H Direction Control Register - - 00h
DP1Lb F104h E 82h P1L Direction Control Register - - 00h
DP1Hb F106h E 83h P1H Direction Control Register - - 00h
RP0Hb F108h E 84h System Start-up Configuration Register (Read only) - - xxh
CC16ICb F160h E B0h CAPCOM Register 16 Interrupt Control Register - - 00h
CC17ICb F162h E B1h CAPCOM Register 17 Interrupt Control Register - - 00h
CC18ICb F164h E B2h CAPCOM Register 18 Interrupt Control Register - - 00h
CC19ICb F166h E B3h CAPCOM Register 19 Interrupt Control Register - - 00h
CC20ICb F168h E B4h CAPCOM Register 20 Interrupt Control Register - - 00h
CC21ICb F16Ah E B5h CAPCOM Register 21 Interrupt Control Register - - 00h
CC22ICb F16Ch E B6h CAPCOM Register 22 Interrupt Control Register - - 00h
CC23ICb F16Eh E B7h CAPCOM Register 23 Interrupt Control Register - - 00h
CC24ICb F170h E B8h CAPCOM Register 24 Interrupt Control Register - - 00h
CC25ICb F172h E B9h CAPCOM Register 25 Interrupt Control Register - - 00h
CC26ICb F174h E BAh CAPCOM Register 26 Interrupt Control Register - - 00h
CC27ICb F176h E BBh CAPCOM Register 27 Interrupt Control Register - - 00h
Table 71. Special function registers ordered by address (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
