Register set UM0404
526/564 DocID13284 Rev 2
CC28IC b F178h E BCh CAPCOM Register 28 Interrupt Control Register - - 00h
T7IC b F17Ah E BDh CAPCOM Timer 7 Interrupt Control Register - - 00h
T8IC b F17Ch E BEh CAPCOM Timer 8 Interrupt Control Register - - 00h
PWMIC b F17Eh E BFh PWM Module Interrupt Control Register - - 00h
CC29IC b F184h E C2h CAPCOM Register 29 Interrupt Control Register - - 00h
XP0IC b F186h E C3h See Section 5.7: X-peripheral interrupt - - 00h
CC30IC b F18Ch E C6h CAPCOM Register 30 Interrupt Control Register - - 00h
XP1IC b F18Eh E C7h See Section 5.7: X-peripheral interrupt - - 00h
CC31IC b F194h E CAh CAPCOM Register 31 Interrupt Control Register - - 00h
XP2IC b F196h E CBh See Section 5.7: X-peripheral interrupt - - 00h
S0TBIC b F19Ch E CEh Serial Channel 0 Transmit Buffer Interrupt Control Reg. - - 00h
XP3IC b F19Eh E CFh See Section 5.7: X-peripheral interrupt - - 00h
EXICON b F1C0h E E0h External Interrupt Control Register 0000h
ODP2 b F1C2h E E1h Port2 Open Drain Control Register 0000h
PICON b F1C4h E E2h Port Input Threshold Control Register - - 00h
ODP3 b F1C6h E E3h Port3 Open Drain Control Register 0000h
ODP4 b F1CAh E E5h Port4 Open Drain Control Register - - 00h
ODP6 b F1CEh E E7h Port6 Open Drain Control Register - - 00h
ODP7 b F1D2h E E9h Port7 Open Drain Control Register - - 00h
ODP8 b F1D6h E EBh Port8 Open Drain Control Register - - 00h
EXISEL b F1DAh E EDh External Interrupt Source Selection Register 0000h
DPP0 FE00h 00h CPU Data Page Pointer 0 Register (10-bit) 0000h
DPP1 FE02h 01h CPU Data Page Pointer 1 Register (10-bit) 0001h
DPP2 FE04h 02h CPU Data Page Pointer 2 Register (10-bit) 0002h
DPP3 FE06h 03h CPU Data Page Pointer 3 Register (10-bit) 0003h
CSP FE08h 04h CPU Code Segment Pointer Register (read only) 0000h
EMUCON FE0Ah 05h Emulation Control Register - - xxh
MDH FE0Ch 06h CPU Multiply Divide Register – High word 0000h
MDL FE0Eh 07h CPU Multiply Divide Register – Low word 0000h
CP FE10h 08h CPU Context Pointer Register FC00h
SP FE12h 09h CPU System Stack Pointer Register FC00h
STKOV FE14h 0Ah CPU Stack Overflow Pointer Register FA00h
STKUN FE16h 0Bh CPU Stack Underflow Pointer Register FC00h
ADDRSEL1 FE18h 0Ch Address Select Register 1 0000h
Table 71. Special function registers ordered by address (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
