ST ST10F276E - Page 527

DocID13284 Rev 2 527/564
UM0404 Register set
ADDRSEL2 FE1Ah 0Dh Address Select Register 2 0000h
ADDRSEL3 FE1Ch 0Eh Address Select Register 3 0000h
ADDRSEL4 FE1Eh 0Fh Address Select Register 4 0000h
PW0 FE30h 18h PWM Module Pulse Width Register 0 0000h
PW1 FE32h 19h PWM Module Pulse Width Register 1 0000h
PW2 FE34h 1Ah PWM Module Pulse Width Register 2 0000h
PW3 FE36h 1Bh PWM Module Pulse Width Register 3 0000h
T2 FE40h 20h GPT1 Timer 2 Register 0000h
T3 FE42h 21h GPT1 Timer 3 Register 0000h
T4 FE44h 22h GPT1 Timer 4 Register 0000h
T5 FE46h 23h GPT2 Timer 5 Register 0000h
T6 FE48h 24h GPT2 Timer 6 Register 0000h
CAPREL FE4Ah 25h GPT2 Capture/Reload Register 0000h
T0 FE50h 28h CAPCOM Timer 0 Register 0000h
T1 FE52h 29h CAPCOM Timer 1 Register 0000h
T0REL FE54h 2Ah CAPCOM Timer 0 Reload Register 0000h
T1REL FE56h 2Bh CAPCOM Timer 1 Reload Register 0000h
MAL FE5Ch 2Eh MAC Unit Accumulator - Low Word 0000h
MAH FE5Eh 2Fh MAC Unit Accumulator - High Word 0000h
CC16 FE60h 30h CAPCOM Register 16 0000h
CC17 FE62h 31h CAPCOM Register 17 0000h
CC18 FE64h 32h CAPCOM Register 18 0000h
CC19 FE66h 33h CAPCOM Register 19 0000h
CC20 FE68h 34h CAPCOM Register 20 0000h
CC21 FE6Ah 35h CAPCOM Register 21 0000h
CC22 FE6Ch 36h CAPCOM Register 22 0000h
CC23 FE6Eh 37h CAPCOM Register 23 0000h
CC24 FE70h 38h CAPCOM Register 24 0000h
CC25 FE72h 39h CAPCOM Register 25 0000h
CC26 FE74h 3Ah CAPCOM Register 26 0000h
CC27 FE76h 3Bh CAPCOM Register 27 0000h
CC28 FE78h 3Ch CAPCOM Register 28 0000h
CC29 FE7Ah 3Dh CAPCOM Register 29 0000h
CC30 FE7Ch 3Eh CAPCOM Register 30 0000h
Table 71. Special function registers ordered by address (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
