ST ST10F276E - Page 528

Register set UM0404
528/564 DocID13284 Rev 2
CC31 FE7Eh 3Fh CAPCOM Register 31 0000h
CC0 FE80h 40h CAPCOM Register 0 0000h
CC1 FE82h 41h CAPCOM Register 1 0000h
CC2 FE84h 42h CAPCOM Register 2 0000h
CC3 FE86h 43h CAPCOM Register 3 0000h
CC4 FE88h 44h CAPCOM Register 4 0000h
CC5 FE8Ah 45h CAPCOM Register 5 0000h
CC6 FE8Ch 46h CAPCOM Register 6 0000h
CC7 FE8Eh 47h CAPCOM Register 7 0000h
CC8 FE90h 48h CAPCOM Register 8 0000h
CC9 FE92h 49h CAPCOM Register 9 0000h
CC10 FE94h 4Ah CAPCOM Register 10 0000h
CC11 FE96h 4Bh CAPCOM Register 11 0000h
CC12 FE98h 4Ch CAPCOM Register 12 0000h
CC13 FE9Ah 4Dh CAPCOM Register 13 0000h
CC14 FE9Ch 4Eh CAPCOM Register 14 0000h
CC15 FE9Eh 4Fh CAPCOM Register 15 0000h
ADDAT FEA0h 50h A/D Converter Result Register 0000h
WDT FEAEh 57h Watchdog Timer Register (read only) 0000h
S0TBUF FEB0h 58h Serial Channel 0 Transmit Buffer Register (write only) 0000h
S0RBUF FEB2h 59h Serial Channel 0 Receive Buffer Register (read only) - xxxh
S0BG FEB4h 5Ah Serial Channel 0 Baud Rate Generator Reload Register 0000h
PECC0 FEC0h 60h PEC Channel 0 Control Register 0000h
PECC1 FEC2h 61h PEC Channel 1 Control Register 0000h
PECC2 FEC4h 62h PEC Channel 2 Control Register 0000h
PECC3 FEC6h 63h PEC Channel 3 Control Register 0000h
PECC4 FEC8h 64h PEC Channel 4 Control Register 0000h
PECC5 FECAh 65h PEC Channel 5 Control Register 0000h
PECC6 FECCh 66h PEC Channel 6 Control Register 0000h
PECC7 FECEh 67h PEC Channel 7 Control Register 0000h
P0L b FF00h 80h Port0 Low Register (Lower half of PORT0) - - 00h
P0H b FF02h 81h Port0 High Register (Upper half of PORT0) - - 00h
P1L b FF04h 82h Port1 Low Register (Lower half of PORT1) - - 00h
P1H b FF06h 83h Port1 High Register (Upper half of PORT1) - - 00h
Table 71. Special function registers ordered by address (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
