ST ST10F276E - Page 529

DocID13284 Rev 2 529/564
UM0404 Register set
IDX0 b FF08h 84h MAC Unit Address Pointer 0 0000h
IDX1 b FF0Ah 85h MAC Unit Address Pointer 1 0000h
BUSCON0 b FF0Ch 86h Bus Configuration Register 0 0xx0h
MDC b FF0Eh 87h CPU Multiply Divide Control Register 0000h
PSW b FF10h 88h CPU Program Status word 0000h
SYSCON b FF12h 89h CPU System Configuration Register 0xx0h
BUSCON1 b FF14h 8Ah Bus Configuration Register 1 0000h
BUSCON2 b FF16h 8Bh Bus Configuration Register 2 0000h
BUSCON3 b FF18h 8Ch Bus Configuration Register 3 0000h
BUSCON4 b FF1Ah 8Dh Bus Configuration Register 4 0000h
ZEROS b FF1Ch 8Eh Constant Value 0’s Register (read only) 0000h
ONES b FF1Eh 8Fh Constant Value 1’s Register (read only) FFFFh
T78CONb FF20h 90h CAPCOM Timer 7 and 8 Control Register 0000h
CCM4 b FF22h 91h CAPCOM Mode Control Register 4 0000h
CCM5 b FF24h 92h CAPCOM Mode Control Register 5 0000h
CCM6 b FF26h 93h CAPCOM Mode Control Register 6 0000h
CCM7 b FF28h 94h CAPCOM Mode Control Register 7 0000h
PWMCON0 b FF30h 98h PWM Module Control Register 0 0000h
PWMCON1 b FF32h 99h PWM Module Control Register 1 0000h
T2CON b FF40h A0h GPT1 Timer 2 Control Register 0000h
T3CON b FF42h A1h GPT1 Timer 3 Control Register 0000h
T4CON b FF44h A2h GPT1 Timer 4 Control Register 0000h
T5CON b FF46h A3h GPT2 Timer 5 Control Register 0000h
T6CON b FF48h A4h GPT2 Timer 6 Control Register 0000h
T01CON b FF50h A8h CAPCOM Timer 0 and Timer 1 Control Register 0000h
CCM0 b FF52h A9h CAPCOM Mode Control Register 0 0000h
CCM1 b FF54h AAh CAPCOM Mode Control Register 1 0000h
CCM2 b FF56h ABh CAPCOM Mode Control Register 2 0000h
CCM3 b FF58h ACh CAPCOM Mode Control Register 3 0000h
T2IC b FF60h B0h GPT1 Timer 2 Interrupt Control Register - - 00h
T3IC b FF62h B1h GPT1 Timer 3 Interrupt Control Register - - 00h
T4IC b FF64h B2h GPT1 Timer 4 Interrupt Control Register - - 00h
T5IC b FF66h B3h GPT2 Timer 5 Interrupt Control Register - - 00h
T6IC b FF68h B4h GPT2 Timer 6 Interrupt Control Register - - 00h
Table 71. Special function registers ordered by address (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
