Register set UM0404
540/564 DocID13284 Rev 2
CAN1BRPER EF0Ch CAN1: BRP Extension Register 0000h
CAN1IF1CR EF10h CAN1: IF1 Command Request 0001h
CAN1IF1CM EF12h CAN1: IF1 Command Mask 0000h
CAN1IF1M1 EF14h CAN1: IF1 Mask 1 FFFFh
CAN1IF1M2 EF16h CAN1: IF1 Mask 2 FFFFh
CAN1IF1A1 EF18h CAN1: IF1 Arbitration 1 0000h
CAN1IF1A2 EF1Ah CAN1: IF1 Arbitration 2 0000h
CAN1IF1MC EF1Ch CAN1: IF1 Message Control 0000h
CAN1IF1DA1 EF1Eh CAN1: IF1 Data A 1 0000h
CAN1IF1DA2 EF20h CAN1: IF1 Data A 2 0000h
CAN1IF1DB1 EF22h CAN1: IF1 Data B 1 0000h
CAN1IF1DB2 EF24h CAN1: IF1 Data B 2 0000h
CAN1IF2CR EF40h CAN1: IF2 Command Request 0001h
CAN1IF2CM EF42h CAN1: IF2 Command Mask 0000h
CAN1IF2M1 EF44h CAN1: IF2 Mask 1 FFFFh
CAN1IF2M2 EF46h CAN1: IF2 Mask 2 FFFFh
CAN1IF2A1 EF48h CAN1: IF2 Arbitration 1 0000h
CAN1IF2A2 EF4Ah CAN1: IF2 Arbitration 2 0000h
CAN1IF2MC EF4Ch CAN1: IF2 Message Control 0000h
CAN1IF2DA1 EF4Eh CAN1: IF2 Data A 1 0000h
CAN1IF2DA2 EF50h CAN1: IF2 Data A 2 0000h
CAN1IF2DB1 EF52h CAN1: IF2 Data B 1 0000h
CAN1IF2DB2 EF54h CAN1: IF2 Data B 2 0000h
CAN1TR1 EF80h CAN1: Transmission Request 1 0000h
CAN1TR2 EF82h CAN1: Transmission Request 2 0000h
CAN1ND1 EF90h CAN1: New Data 1 0000h
CAN1ND2 EF92h CAN1: New Data 2 0000h
CAN1IP1 EFA0h CAN1: Interrupt Pending 1 0000h
CAN1IP2 EFA2h CAN1: Interrupt Pending 2 0000h
CAN1MV1 EFB0h CAN1: Message Valid 1 0000h
CAN1MV2 EFB2h CAN1: Message Valid 2 0000h
Table 73. X-Registers ordered by address (continued)
Name Physical address Description
Reset
value
