UM0404 Register set
CAN2IF1M1 EE14h CAN2: IF1 Mask 1 FFFFh
CAN2IF1M2 EE16h CAN2: IF1 Mask 2 FFFFh
CAN2IF1A1 EE18h CAN2: IF1 Arbitration 1 0000h
CAN2IF1A2 EE1Ah CAN2: IF1 Arbitration 2 0000h
CAN2IF1MC EE1Ch CAN2: IF1 Message Control 0000h
CAN2IF1DA1 EE1Eh CAN2: IF1 Data A 1 0000h
CAN2IF1DA2 EE20h CAN2: IF1 Data A 2 0000h
CAN2IF1DB1 EE22h CAN2: IF1 Data B 1 0000h
CAN2IF1DB2 EE24h CAN2: IF1 Data B 2 0000h
CAN2IF2CR EE40h CAN2: IF2 Command Request 0001h
CAN2IF2CM EE42h CAN2: IF2 Command Mask 0000h
CAN2IF2M1 EE44h CAN2: IF2 Mask 1 FFFFh
CAN2IF2M2 EE46h CAN2: IF2 Mask 2 FFFFh
CAN2IF2A1 EE48h CAN2: IF2 Arbitration 1 0000h
CAN2IF2A2 EE4Ah CAN2: IF2 Arbitration 2 0000h
CAN2IF2MC EE4Ch CAN2: IF2 Message Control 0000h
CAN2IF2DA1 EE4Eh CAN2: IF2 Data A 1 0000h
CAN2IF2DA2 EE50h CAN2: IF2 Data A 2 0000h
CAN2IF2DB1 EE52h CAN2: IF2 Data B 1 0000h
CAN2IF2DB2 EE54h CAN2: IF2 Data B 2 0000h
CAN2TR1 EE80h CAN2: Transmission Request 1 0000h
CAN2TR2 EE82h CAN2: Transmission Request 2 0000h
CAN2ND1 EE90h CAN2: New Data 1 0000h
CAN2ND2 EE92h CAN2: New Data 2 0000h
CAN2IP1 EEA0h CAN2: Interrupt Pending 1 0000h
CAN2IP2 EEA2h CAN2: Interrupt Pending 2 0000h
CAN2MV1 EEB0h CAN2: Message Valid 1 0000h
CAN2MV2 EEB2h CAN2: Message Valid 2 0000h
CAN1CR EF00h CAN1: CAN Control Register 0001h
CAN1SR EF02h CAN1: Status Register 0000h
CAN1EC EF04h CAN1: Error Counter 0000h
CAN1BTR EF06h CAN1: Bit Timing Register 2301h
CAN1IR EF08h CAN1: Interrupt Register 0000h
CAN1TR EF0Ah CAN1: Test Register 00x0h
Table 73. X-Registers ordered by address (continued)
Name Physical address Description
Reset
value
