Register set UM0404
538/564 DocID13284 Rev 2
XPWMCON1SET EC0Ah
XPWM Module Set Control Register 0
(write only)
0000h
XPWMCON1CLR EC0Ch
XPWM Module Clear Control Reg. 0 (write
only)
0000h
XPT0 EC10h XPWM Module Up/Down Counter 0 0000h
XPT1 EC12h XPWM Module Up/Down Counter 1 0000h
XPT2 EC14h XPWM Module Up/Down Counter 2 0000h
XPT3 EC16h XPWM Module Up/Down Counter 3 0000h
XPP0 EC20h XPWM Module Period Register 0 0000h
XPP1 EC22h XPWM Module Period Register 1 0000h
XPP2 EC24h XPWM Module Period Register 2 0000h
XPP3 EC26h XPWM Module Period Register 3 0000h
XPW0 EC30h XPWM Module Pulse Width Register 0 0000h
XPW1 EC32h XPWM Module Pulse Width Register 1 0000h
XPW2 EC34h XPWM Module Pulse Width Register 2 0000h
XPW3 EC36h XPWM Module Pulse Width Register 3 0000h
XPWMPORT EC80h XPWM Module Port Control Register 0000h
RTCCON ED00H RTC Control Register 0x00h
RTCPL ED06h RTC Prescaler Register Low Byte xxxxh
RTCPH ED08h RTC Prescaler Register High Byte xxxxh
RTCDL ED0Ah RTC Divider Counter Low Byte xxxxh
RTCDH ED0Ch RTC Divider Counter High Byte xxxxh
RTCL ED0Eh RTC Programmable Counter Low Byte xxxxh
RTCH ED10h RTC Programmable Counter High Byte xxxxh
RTCAL ED12h RTC Alarm Register Low Byte xxxxh
RTCAH ED14h RTC Alarm Register High Byte xxxxh
CAN2CR EE00h CAN2: CAN Control Register 0001h
CAN2SR EE02h CAN2: Status Register 0000h
CAN2EC EE04h CAN2: Error Counter 0000h
CAN2BTR EE06h CAN2: Bit Timing Register 2301h
CAN2IR EE08h CAN2: Interrupt Register 0000h
CAN2TR EE0Ah CAN2: Test Register 00x0h
CAN2BRPER EE0Ch CAN2: BRP Extension Register 0000h
CAN2IF1CR EE10h CAN2: IF1 Command Request 0001h
CAN2IF1CM EE12h CAN2: IF1 Command Mask 0000h
Table 73. X-Registers ordered by address (continued)
Name Physical address Description
Reset
value
