UM0404 Register set
I2COAR1 EA08h I2C Own Address Register 1 0000h
I2COAR2 EA0Ah I2C Own Address Register 1 0000h
I2CDR EA0Ch I2C Data Register 0000h
I2CCCR2 EA0Eh I2C Clock Control Register 2 0000h
XCLKOUTDIV EB02h CLKOUT Divider Control Register - - 00h
XIR0SEL EB10h X-Interrupt 0 Selection Register 0000h
XIR0SET EB12h X-Interrupt 0 Set Register (write only) 0000h
XIR0CLR EB14h X-Interrupt 0 Clear Register (write only) 0000h
XIR1SEL EB20h X-Interrupt 1 Selection Register 0000h
XIR1SET EB22h X-Interrupt 1 Set Register (write only) 0000h
XIR1CLR EB24h X-Interrupt 1 Clear Register (write only) 0000h
XPICON EB26h
Extended Port Input Threshold Control
Register
- - 00h
XIR2SEL EB30h X-Interrupt 2 Selection Register 0000h
XIR2SET EB32h X-Interrupt 2 Set Register (write only) 0000h
XIR2CLR EB34h X-Interrupt 2 Clear Register (write only) 0000h
XP1DIDIS EB36h PORT1 Digital Disable Register 0000h
XIR3SEL EB40h X-Interrupt 3 Selection Register 0000h
XIR3SET EB42h
X-Interrupt 3 Set Selection Register (write
only)
0000h
XIR3CLR EB44h
X-Interrupt 3 Clear Selection Register
(write only)
0000h
XMISC EB46h XBUS Miscellaneous Features Register 0000h
XEMU0 EB76h XBUS Emulation Register 0 (write only) xxxxh
XEMU1 EB78h XBUS Emulation Register 1 (write only) xxxxh
XEMU2 EB7Ah XBUS Emulation Register 2 (write only) xxxxh
XEMU3 EB7Ch XBUS Emulation Register 3 (write only) xxxxh
XPEREMU EB7Eh XPERCON copy for Emulation (write only) xxxxh
XPWMCON0 EC00h XPWM Module Control Register 0 0000h
XPWMCON1 EC02h XPWM Module Control Register 1 0000h
XPOLAR EC04h XPWM Module Channel Polarity Register 0000h
XPWMCON0SET EC06h
XPWM Module Set Control Register 0
(write only)
0000h
XPWMCON0CLR EC08h
XPWM Module Clear Control Reg. 0 (write
only)
0000h
Table 73. X-Registers ordered by address (continued)
Name Physical address Description
Reset
value
