DocID13284 Rev 2 425/564
UM0404 CAN modules
Note: The busoff recovery sequence (see CAN Specification Rev. 2.0) cannot be shortened by
setting or resetting bit Init. If the device goes busoff, it will set bit Init of its own accord,
stopping all bus activities. Once bit Init has been cleared by the CPU, the device will then
wait for 129 occurrences of Bus Idle (129 * 11 consecutive recessive bits) before resuming
normal operations. At the end of the busoff recovery sequence, the Error Management
Counters will be reset.
During the waiting time after the resetting of bit Init, each time a sequence of 11 recessive
bits has been monitored, a Bit0Error code is written to the Status Register, enabling the
CPU to readily check up whether the CAN bus is stuck at dominant or continuously
disturbed and to monitor the proceeding of the busoff recovery sequence.
Status Register
CAN1SR (EF02h) XBUS Reset Value: 0000h
CAN2SR (EE02h) XBUS Reset Value: 0000h
EIE
Error Interrupt Enable
‘0’: Disabled - No Error Status Interrupt will be generated.
‘1’: Enabled - A change in the bits BOff or EWarn in the Status Register will
generate an interrupt.
DAR
Disable Automatic Retransmission
‘0’: Automatic Retransmission of disturbed messages enabled.
‘1’: Automatic Retransmission disabled.
CCE
Configuration Change Enable
‘0’: The CPU has no write access to the Bit Timing Register.
‘1’: The CPU has write access to the Bit Timing Register (while Init = one).
Te s t
Test Mode enable
‘0’: Normal Operation.
‘1’: Test mode.
Bit Function
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
--------BOff EWarn EPass RxOk TxOk LEC
RRRRWRW RW
