Note: With a CAN module clock of 8 MHz, the reset value of 0x2301 configures the C-CAN for a
bitrate of 500 Kbit/s. The registers are only writable if bits CCE and Init in the CAN Control
Register are set.
Test register
CAN1TR (EF0Ah) XBUS Reset Value: 00x0h
CAN2TR (EE0Ah) XBUS Reset Value: 00x0h
Write access to the Test Register is enabled by setting bit Test in the CAN Control Register.
The different test functions may be combined, but Tx(1:0) ≠ “00” disturbs message transfer.
TSeg1
Time segment before the sample point
Valid values for TSeg1 are 01h-0Fh (1…15). The actual interpretation by the
hardware of this value is such that one more than the value programmed here is
used.
TSeg2
Time segment after the sample point
Valid values for TSeg2 are 0h-7h (0…7). The actual interpretation by the hardware
of this value is such that one more than the value programmed here is used.
Bit Function
1514131211109876543210
--------RxTx(1:0)LBackSilentBasic -
RW RW RW RW RW
Bit Function
Basic
Basic Mode
’0’: Basic Mode disabled.
’1’: IF1 Registers used as Tx Buffer, IF2 Registers used as Rx Buffer.
Silent
Silent Mode
’0’: Normal operation.
’1’: The module is in Silent Mode.
LBack
Loop Back Mode
’0’: Loop Back Mode is disabled.
’1’: Loop Back Mode is enabled.
Tx(1:0)
CAN_TxD pin control
’00’: Reset value, CAN_TxD is controlled by the CAN Core.
’01’: Sample Point can be monitored at CAN_TxD pin.
’10’: CAN_TxD pin drives a dominant (‘0’) value.
’11’: CAN_TxD pin drives a recessive (‘1’) value.
Rx
Actual CAN_RxD pin value monitor
’0’: The CAN bus is dominant (CAN_RxD = ‘0’).
’1’: The CAN bus is recessive (CAN_RxD = ‘1’).
