DocID13284 Rev 2 533/564
UM0404 Register set
CAN2IF1CR EE10h CAN2: IF1 Command Request 0001h
CAN2IF1DA1 EE1Eh CAN2: IF1 Data A 1 0000h
CAN2IF1DA2 EE20h CAN2: IF1 Data A 2 0000h
CAN2IF1DB1 EE22h CAN2: IF1 Data B 1 0000h
CAN2IF1DB2 EE24h CAN2: IF1 Data B 2 0000h
CAN2IF1M1 EE14h CAN2: IF1 Mask 1 FFFFh
CAN2IF1M2 EE16h CAN2: IF1 Mask 2 FFFFh
CAN2IF1MC EE1Ch CAN2: IF1 Message Control 0000h
CAN2IF2A1 EE48h CAN2: IF2 Arbitration 1 0000h
CAN2IF2A2 EE4Ah CAN2: IF2 Arbitration 2 0000h
CAN2IF2CM EE42h CAN2: IF2 Command Mask 0000h
CAN2IF2CR EE40h CAN2: IF2 Command Request 0001h
CAN2IF2DA1 EE4Eh CAN2: IF2 Data A 1 0000h
CAN2IF2DA2 EE50h CAN2: IF2 Data A 2 0000h
CAN2IF2DB1 EE52h CAN2: IF2 Data B 1 0000h
CAN2IF2DB2 EE54h CAN2: IF2 Data B 2 0000h
CAN2IF2M1 EE44h CAN2: IF2 Mask 1 FFFFh
CAN2IF2M2 EE46h CAN2: IF2 Mask 2 FFFFh
CAN2IF2MC EE4Ch CAN2: IF2 Message Control 0000h
CAN2IP1 EEA0h CAN2: Interrupt Pending 1 0000h
CAN2IP2 EEA2h CAN2: Interrupt Pending 2 0000h
CAN2IR EE08h CAN2: Interrupt Register 0000h
CAN2MV1 EEB0h CAN2: Message Valid 1 0000h
CAN2MV2 EEB2h CAN2: Message Valid 2 0000h
CAN2ND1 EE90h CAN2: New Data 1 0000h
CAN2ND2 EE92h CAN2: New Data 2 0000h
CAN2SR EE02h CAN2: Status Register 0000h
CAN2TR EE0Ah CAN2: Test Register 00x0h
CAN2TR1 EE80h CAN2: Transmission Request 1 0000h
CAN2TR2 EE82h CAN2: Transmission Request 2 0000h
I2CCCR1 EA06h I2C Clock Control Register 1 0000h
I2CCCR2 EA0Eh I2C Clock Control Register 2 0000h
I2CCR EA00h I2C Control Register 0000h
I2CDR EA0Ch I2C Data Register 0000h
Table 72. X-Registers ordered by name (continued)
Name Physical address Description
Reset
value
