UM0404 Register set
XPICON EB26h
Extended Port Input Threshold Control
Register
- - 00h
XPOLAR EC04h XPWM Module Channel Polarity Register 0000h
XPP0 EC20h XPWM Module Period Register 0 0000h
XPP1 EC22h XPWM Module Period Register 1 0000h
XPP2 EC24h XPWM Module Period Register 2 0000h
XPP3 EC26h XPWM Module Period Register 3 0000h
XPT0 EC10h XPWM Module Up/Down Counter 0 0000h
XPT1 EC12h XPWM Module Up/Down Counter 1 0000h
XPT2 EC14h XPWM Module Up/Down Counter 2 0000h
XPT3 EC16h XPWM Module Up/Down Counter 3 0000h
XPW0 EC30h XPWM Module Pulse Width Register 0 0000h
XPW1 EC32h XPWM Module Pulse Width Register 1 0000h
XPW2 EC34h XPWM Module Pulse Width Register 2 0000h
XPW3 EC36h XPWM Module Pulse Width Register 3 0000h
XPWMCON0 EC00h XPWM Module Control Register 0 0000h
XPWMCON0CLR EC08h
XPWM Module Clear Control Reg. 0 (write
only)
0000h
XPWMCON0SET EC06h
XPWM Module Set Control Register 0
(write only)
0000h
XPWMCON1 EC02h XPWM Module Control Register 1 0000h
XPWMCON1CLR EC0Ch
XPWM Module Clear Control Reg. 0 (write
only)
0000h
XPWMCON1SET EC0Ah
XPWM Module Set Control Register 0
(write only)
0000h
XPWMPORT EC80h XPWM Module Port Control Register 0000h
XS1BG E906h
XASC Baud Rate Generator Reload
Register
0000h
XS1CON E900h XASC Control Register 0000h
XS1CONCLR E904h XASC Clear Control Register (write only) 0000h
XS1CONSET E902h XASC Set Control Register (write only) 0000h
XS1PORT E980h XASC Port Control Register 0000h
XS1RBUF E90Ah XASC Receive Buffer Register - xxxh
XS1TBUF E908h XASC Transmit Buffer Register 0000h
XSSCBR E80Ah XSSC Baud Rate Register 0000h
XSSCCON E800h XSSC Control Register 0000h
Table 72. X-Registers ordered by name (continued)
Name Physical address Description
Reset
value
