The central processing unit (CPU) UM0404

80/564 DocID13284 Rev 2

manipulation or mask generation. It can be accessed via any instruction which is capable of

addressing an SFR.

ZEROS (FF1Ch / 8Eh) SFR Reset Value: 0000h

1514131211109876543210

0000000000000000

RRRRRRRRRRRRRRRR
