3.5L ENGINE
DESCRIPTION SPECIFICATION
Type 60° SOHC V-6 24-Valve
Displacement 3.5 Liters
(214 Cubic Inches)
Bore and Stroke 96.0 x 81.0 mm
(3.780 x 3.189 in.)
Compression Ratio 9.9:1
Lead Cylinder #1 Right Bank
Firing Order 1-2-3-4-5-6
Cylinder Block
Cylinder Bore Diameter 96.0 mm 60.0076
(3.780 in. 60.0003 in.)
Out-of-Round (Max.) 0.076 mm
(0.003 in.)
Taper (Max.) 0.051 mm
(0.002 in.)
Pistons
Type Material Aluminum (Full Floating
Pins)
Clearance at Size
Location
–0.007 to +0.047 mm
(–0.0003 to +0.0018 in.)
Piston Weight
—A Size 438–443 grams
(15.45–15.62 oz.)
—B Size 433–438 grams
(15.27–15.45 oz.)
Piston Ring Groove
Diameter
—No. 1 87.4–87.6 mm
(3.441–3.449 in.)
—No. 2 86.3–86.5 mm
(3.397–3.4055 in.)
—No. 3 85.8–86.0 mm
(3.378–3.385 in.)
Piston Pins
Type Full Floating
Clearance in Piston 0.005–0.015 mm
(0.0002–0.0006 in.)
Clearance in Rod 0.007–0.018 mm
(0.0003–0.007 in.)
DESCRIPTION SPECIFICATION
Diameter 23.997–24.000 mm
(0.9448–0.9449 in.)
Piston Rings
Ring Gap—Top
Compression Ring
0.20–0.36 mm
(0.008–0.014 in.)
Ring Gap—2nd
Compression Ring
0.23–0.50 mm
(0.0091–0.0197 in.)
Ring Gap—Oil Control
(Steel Rails)
0.25–0.76 mm
(0.010–0.030 in.)
Ring Groove Clearance
Top and Second
Compression Ring
0.035–0.085 mm
(0.0014–0.0034 in.)
Oil Ring (Steel Rails) 0.038–0.184 mm
(0.0015–0.0073 in.)
Ring Width
Top Compression Ring 1.17–1.19 mm
(0.0461–0.0469 in.)
2nd Compression Ring 1.47–1.49 mm
(0.058–0.059 in.)
Oil Ring (Steel Rings) 0.445–0.470 mm
(0.0176–0.0186 in.)
Connecting Rods
Bearing Clearance 0.019–0.087 mm
(0.0007–0.0034 in.)
Piston Pin Bore Diameter 24.0076–24.0153 mm
(0.9452–0.9455 in.)
Side Clearance (Max.) 0.40 mm
(0.0157 in.)
Total Weight (Less
Bearing)
647 grams
(22.8223 oz.)
Crankshaft Main Bearing Journals
Diameter 63.987–64.013 mm
(2.519–2.520 in.)
Main Bearing Diametrical
Clearance
0.011–0.077 mm
(0.0007–0.0030 in.)
—(Max. Allowable) 0.087 mm
(0.0034 in.)
Out-of-Round (Max.) 0.015 mm
(0.0006 in.)
Taper (Max.) 0.015 mm
(0.0006 in)
9 - 146 3.2/3.5L ENGINE LH
SPECIFICATIONS (Continued)
