DESCRIPTION SPECIFICATION
Valves
Face Angle 44.5–45°
Head Diameter—Intake 36.37–36.63 mm
(1.4319–1.4421 in.)
Head Diameter—Exhaust 28.87–29.13 mm
(1.1366–1.1469 in.)
Length—Intake (Overall) 114.41–114.99 mm
(4.5043–4.5272 in.)
Length—Exhaust
(Overall)
125.67–126.25 mm
(4.9476–4.9705 in.)
Stem Diameter—Intake 6.935–6.953 mm
(0.2730–0.2737 in.)
Stem Diameter—Exhaust 6.906–6.924 mm
(0.2719–0.2726 in.)
Stem-to-Guide
Clearance—Intake
0.022–0.065 mm
(0.0009–0.0026 in.)
—(Max.) Rocking Method 0.29 mm
(0.0114 in.)
Stem-to-Guide
Clearance—Exhaust
0.051–0.094 mm
(0.002–0.0037 in.)
—(Max.) Rocking Method 0.370 mm
(0.0146 in.)
Valve Lift—Intake (Zero
Lash)
8.55 mm
(0.3367 in.)
Valve Lift—Exhaust (Zero
Lash)
6.53 mm
(0.2571 in.)
Valve Stem Tip
Height—Intake
42.366–43.655 mm
(1.6680–1.7187 in.)
Valve Stem Tip
Height—Exhaust
44.705–45.986 mm
(1.760–1.8105 in.)
Valve Springs
Free Length—Intake
(Approx.)
43.675 mm
(1.7195 in.)
Free Length—Exhaust
(Approx.)
44.319 mm
(1.7448 in.)
Spring Force—Intake
(Valve Closed)
309–358 N @ 38.0 mm
(69.5–80.5 lbs. @ 1.4961
in.)
Spring Force—Exhaust
(Valve Closed)
314–354 N @ 38.0 mm
(71–79 lbs. @ 1.4961 in.)
DESCRIPTION SPECIFICATION
Spring Force—Intake
(Valve Open)
836–907 N @ 29.85 mm
(188–204 lbs. @ 1.1594
in.)
Spring Force—Exhaust
(Valve Open)
579–640 N @ 31.47 mm
(130–144 lbs. @ 1.239
in.)
Number of Coils—Intake 6.86
Number of Coils—
Exhaust
7.66
Color of Spring (Top of
Coils)
—Intake (Right Hand Coil
Direction)
Orange
—Exhaust (Left Hand
Coil Direction)
Yellow
Wire Diameter—Intake 4.29–4.35 mm
(0.1689–0.1712 in.)
Wire Diameter—Exhaust 4.09–4.15 mm
(0.1608–0.1632 in.)
Spring Installed Height
(Spring Seat to Bottom of
Retainer)—Intake &
Exhaust
38.0 mm
(1.4961 in.)
Oil Pump
Clearance Over Rotors 0.077 mm
(0.003 in.)
Cover Out-of-Flat (Max.) 0.025 mm
(0.001 in.)
Inner & Outer Rotor
Thickness (MIn.)
14.299 mm
(0.563 in.)
Outer Rotor Thickness
(Max.)
0.39 mm
(0.015 in.)
Outer Rotor Diameter
(Min.)
79.997 mm
(3.149 in.)
Tip Clearance Between
Rotors (Max.)
0.20 mm
(0.008 in.)
Oil Pressure
@ Curb Idle Speed* 34.47 kPa
(5 psi)
@ 3000 rpm 170–724 kPa
(25–105 psi)
*CAUTION: If pressure is zero at curb idle, DO NOT
run engine at 3000 rpm.
LH 3.2/3.5L ENGINE 9 - 145
