DESCRIPTION SPECIFICATION
Ring Width
Top Compression Ring 1.17–1.19 mm
(0.0461–0.0469 in.)
2nd Compression Ring 1.47–1.49 mm
(0.0580–0.0587 in.)
Oil Ring (Steel Rings) 0.445–0.470 mm
(0.0176–0.0186 in.)
Connecting Rods
Bearing Clearance 0.019–0.087 mm
(0.0007–0.0034 in.)
Piston Pin Bore Diameter 24.0076–24.0153 mm
(0.9452–0.9455 in.)
Side Clearance (Max.) 0.40 mm
(0.0157 in.)
Total Weight (Less
Bearing)
647 grams
(22.8223 oz.)
Crankshaft Main Bearing Journals
Diameter 63.987–64.013 mm
(2.519–2.520 in.)
Main Bearing Diametrical
Clearance
0.011–0.077 mm
(0.0007–0.0030 in.)
—(Max. Allowable) 0.087 mm
(0.0034 in.)
Out-of-Round (Max.) 0.015 mm
(0.0006 in.)
Taper (Max.) 0.015 mm
(0.0006 in)
End Play 0.10–0.30 mm
(0.004–0.012 in.)
—(Max.) 0.43 mm
(0.017 in.)
Connecting Rod Journals
Diameter 57.979–58.005 mm
(2.283–2.284 in.)
Bearing Diametrical
Clearance
0.019–0.087 mm
(0.00075–0.0034 in.)
Out-of-Round (Max.) 0.015 mm
(0.0006 in.)
Taper (Max.) 0.015 mm
(0.0006 in.)
DESCRIPTION SPECIFICATION
Camshaft
Bore Diameter 43.038–43.059 mm
(1.6944–1.6952 in.)
Bearing Journal Diameter 42.939–42.960 mm
(1.6905–1.6913 in.)
Diametrical Clearance 0.078–0.12 mm
(0.003–0.0047 in.)
—(Max.) 0.15 mm
(0.0059 in.)
End Play 0.11–0.35 mm
(0.004–0.014 in.)
Valve Timing—Intake Valve
Opens (ATDC) 1°
Closes (ABDC) 51°
Duration 230°
Centerline 116°
Valve Timing—Exhaust Valve
Opens (BBDC) 48°
Closes (ATDC) 12°
Duration 240°
Centerline 108°
Valve Overlap 11°
Cylinder Head
Gasket Thickness
(Compressed)
1.78 mm
(0.070 in.)
Valve Seat Angle 45–45.5°
Valve Seat Runout (Max.) 0.051 mm
(0.002 in.)
Valve Seat Width—Intake 0.75–1.25 mm
(0.0295–0.0492 in.)
Valve Seat Width—
Exhaust
1.25–1.75 mm
(0.0492–0.0689 in.)
Guide Bore Diameter
(Std.)
6.975–7.00 mm
(0.2746–0.2756 in.)
Valve Guide Height* 9.5–10.5 mm
(0.3740–0.4134 in.)
*Measured from cylinder head surface
9 - 144 3.2/3.5L ENGINE LH
SPECIFICATIONS (Continued)
