Splice
Number
Location Fig.
S127 Headlamp and Dash in Power
Distribution Center
N/S
S128 Headlamp and Dash in Power
Distribution Center
N/S
S130 Front Lighting Near T/O for Left
Front Lamps
2
S131 Front Lighting Near T/O for Left
Front Lamps
2
S132 Front Lighting Near T/O for Left
Front Lamps
2
S133 Front Lighting Near T/O for Left
Front Lamps
2
S134 Front Lighting Near T/O for Left
Front Lamps
2
S135 Front Lighting Near T/O for
Right Front Lamps
1
S140 Fuel Tank Jumper Near Fuel
Pump Module
N/S
S141 Transmission Harness Near
T/O for Oxygen Sensors
5
S142 Transmission Harness Near
Near T/O for Oxygen Sensors
5
S143 Transmission Harness Near
Near T/O for Oxygen Sensors
5
S144 Engine Harness in T/O to
Battery
3, 4
S145 Engine Harness in T/O to
Battery
3, 4
S146 Transmission Harness Near
T/O to Output Shaft Speed
Sensor
5
S147 Headlamp and Dash Left Inner
Fender
2
S160 Front Fascia Harness Between
Right and Left Headlamps
N/S
S161 Front Fascia Harness Between
Right and Left Headlamps
N/S
S162 Front Fascia Harness Between
Right and Left Headlamps
N/S
S163 Headlamp and Dash Harness
Near T/O Brake Pressure
Switch
10
S164 Headlamp and Dash Harness
Near T/O for Left Front Wheel
Speed Sensor
10
S165 Headlamp and Dash Harness
in Power Distribution Center
N/S
Splice
Number
Location Fig.
S166 Headlamp and Dash Harness
in Power Distribution Center
N/S
S167 Headlamp and Dash Harness
in Power Distribution Center
N/S
S168 Headlamp and Dash Harness
in Power Distribution Center
N/S
S170 Headlamp and Dash Harness
Near T/O to Front End Lighting
2
S200 Instrument Panel Left Side 6
S201 Instrument Panel Left Side 6
S202 Instrument Panel Left Side 6
S203 Instrument Panel Left Side 6
S204 Instrument Panel Behind
Cluster
6
S205 Instrument Panel Left Side 6
S206 Instrument Panel Center 6
S207 Instrument Panel Center 6
S208 Instrument Panel Center 6
S209 Instrument Panel Right Side 6
S210 A/C Heater Harness N/S
S111 A/C Heater Harness N/S
S212 A/C Heater Harness N/S
S213 Instrument Panel Left Side 6
S214 Instrument Panel, Behind
Cluster
6
S215 Instrument Panel Left Side 6
S300 Body Harness Left Cowl 8
S301 Body Harness Left Front Sill 8
S302 Body Harness Left Front Sill 8
S303 Body Harness Right Body Rear 9
S304 Body Harness Right Body Rear 9
S305 Body Harness Under Drivers
Seat
8
S306 Body Harness Body Rear N/S
S307 Body Harness Left Body Rear N/S
S308 Body Harness Left Body Rear N/S
S309 Body Harness Left Body Rear N/S
S310 Body Harness Left Body Rear N/S
S311 Right Front Door Harness 7
S312 Left Front Door Harness N/S
S313 Right Front Door Harness 7
S314 Left Front Door Harness N/S
S315 Left Front Door Harness N/S
8W - 95 - 2 8W - 95 SPLICE LOCATIONS LH
DESCRIPTION AND OPERATION (Continued)
