Splice
Number
Location Fig.
S316 Left Front Door Harness N/S
S317 Left Front Door Harness N/S
S318 Left Front Door Harness N/S
S319 Headliner Harness Near T/O to
Day/Night Mirror
N/S
S320 Headliner Harness Near T/O to
Day/Night Mirror
N/S
S321 Headliner Harness Near T/O to
Day/Night Mirror
N/S
S322 Headliner Harness Near T/O to
Day/Night Mirror
N/S
S323 Headliner Harness Near T/O to
Day/Night Mirror
N/S
S324 Headliner Harness Near T/O to
Left Rear Door Courtesy Lamp
N/S
S325 Headliner Harness Near T/O to
Left Rear Door Courtesy Lamp
N/S
S326 Headliner Harness Near T/O to
Right Rear Door Courtesy
Lamp
N/S
S327 Headliner Harness Near T/O to
Right Rear Door Courtesy
Lamp
N/S
S328 Power Seat Harness at Seat N/S
S329 Body Harness, Right Body
Rear
9
S330 Body Harness, Right Body
Rear
9
S331 Body Harness, Left Side Body 8
S332 Body Harness, Right Side
Body
9
S334 Body Harness, Left Side Body 8
S335 Body Harness, Left Side Body 8
S336 Body Harness, Left Cowl 8
S337 Body Harness, Body Rear N/S
Splice
Number
Location Fig.
S338 Body Harness, Right Side
Body
9
S341 Memory Seat Harness Near
T/O to Seat Motors
N/S
S342 Memory Seat Harness Near
Heated Seat Heater Connector
N/S
S343 Memory Seat Harness Near
Heated Seat Heater Connector
N/S
S345 Body Harness, Left Front Sill 8
S346 Body Harness, Left Front Sill 8
S347 Body Harness, Left Front Sill 8
S400 Taillamp Harness in T/O to
Rear Fog Lamp
N/S
S401 Rear Fascia Harness N/S
S402 Taillamp Harness, Left Tail
Lamps
N/S
S403 Taillamp Harness, Left Tail
Lamps
N/S
S404 Taillamp Harness, Left Tail
Lamps
N/S
S405 Deck Lid Harness N/S
S407 Taillamp Harness, Left Tail
Lamps
N/S
S408 Taillamp Harness, Left Tail
Lamps
N/S
S409 Taillamp Harness, Left Tail
Lamps
N/S
S411 Near T/O for Sun Roof Motor
Connector
N/S
S412 Near T/O for Sun Roof Motor
Connector
N/S
S421 Taillamp Harness in T/O to
Rear Fog Lamp
N/S
LH 8W - 95 SPLICE LOCATIONS 8W - 95 - 3
DESCRIPTION AND OPERATION (Continued)
