ST ST10F276E - Page 520

Register set UM0404
520/564 DocID13284 Rev 2
CCM4 b FF22h 91h CAPCOM Mode Control Register 4 0000h
CCM5 b FF24h 92h CAPCOM Mode Control Register 5 0000h
CCM6 b FF26h 93h CAPCOM Mode Control Register 6 0000h
CCM7 b FF28h 94h CAPCOM Mode Control Register 7 0000h
CP FE10h 08h CPU Context Pointer Register FC00h
CRIC b FF6Ah B5h GPT2 CAPREL Interrupt Control Register - - 00h
CSP FE08h 04h CPU Code Segment Pointer Register (read only) 0000h
DP0L b F100h E 80h P0L Direction Control Register - - 00h
DP0H b F102h E 81h P0h Direction Control Register - - 00h
DP1L b F104h E 82h P1L Direction Control Register - - 00h
DP1H b F106h E 83h P1h Direction Control Register - - 00h
DP2 b FFC2h E1h Port2 Direction Control Register 0000h
DP3 b FFC6h E3h Port3 Direction Control Register 0000h
DP4 b FFCAh E5h Port4 Direction Control Register - - 00h
DP6 b FFCEh E7h Port6 Direction Control Register - - 00h
DP7 b FFD2h E9h Port7 Direction Control Register - - 00h
DP8 b FFD6h EBh Port8 Direction Control Register - - 00h
DPP0 FE00h 00h CPU Data Page Pointer 0 Register (10-bit) 0000h
DPP1 FE02h 01h CPU Data Page Pointer 1 Register (10-bit) 0001h
DPP2 FE04h 02h CPU Data Page Pointer 2 Register (10-bit) 0002h
DPP3 FE06h 03h CPU Data Page Pointer 3 Register (10-bit) 0003h
EMUCON FE0Ah 05h Emulation Control Register - - xxh
EXICON b F1C0h E E0h External Interrupt Control Register 0000h
EXISEL b F1DAh E EDh External Interrupt Source Selection Register 0000h
IDCHIP F07Ch E 3Eh Device Identifier Register (n is the device revision) 114nh
IDMANUF F07Eh E 3Fh Manufacturer Identifier Register 0403h
IDMEM F07Ah E 3Dh On-chip Memory Identifier Register 30D0h
IDPROG F078h E 3Ch Programming Voltage Identifier Register 0040h
IDX0 b FF08h 84h MAC Unit Address Pointer 0 0000h
IDX1 b FF0Ah 85h MAC Unit Address Pointer 1 0000h
MAH FE5Eh 2Fh MAC Unit Accumulator - High Word 0000h
MAL FE5Ch 2Eh MAC Unit Accumulator - Low Word 0000h
MCW b FFDCh EEh MAC Unit Control Word 0000h
MDC b FF0Eh 87h CPU Multiply Divide Control Register 0000h
Table 70. Special function registers ordered by name (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
