Register set UM0404
522/564 DocID13284 Rev 2
PP2 F03Ch E 1Eh PWM Module Period Register 2 0000h
PP3 F03Eh E 1Fh PWM Module Period Register 3 0000h
PSW b FF10h 88h CPU Program Status Word 0000h
PT0 F030h E 18h PWM Module Up/Down Counter 0 0000h
PT1 F032h E 19h PWM Module Up/Down Counter 1 0000h
PT2 F034h E 1Ah PWM Module Up/Down Counter 2 0000h
PT3 F036h E 1Bh PWM Module Up/Down Counter 3 0000h
PW0 FE30h 18h PWM Module Pulse Width Register 0 0000h
PW1 FE32h 19h PWM Module Pulse Width Register 1 0000h
PW2 FE34h 1Ah PWM Module Pulse Width Register 2 0000h
PW3 FE36h 1Bh PWM Module Pulse Width Register 3 0000h
PWMCON0 b FF30h 98h PWM Module Control Register 0 0000h
PWMCON1 b FF32h 99h PWM Module Control Register 1 0000h
PWMIC b F17Eh E BFh PWM Module Interrupt Control Register - - 00h
QR0 F004h E 02h MAC Unit Offset Register R0 0000h
QR1 F006h E 03h MAC Unit Offset Register R1 0000h
QX0 F000h E 00h MAC Unit Offset Register X0 0000h
QX1 F002h E 01h MAC Unit Offset Register X1 0000h
RP0H b F108h E 84h System Start-up Configuration Register (read only) - - xxh
S0BG FEB4h 5Ah Serial Channel 0 Baud Rate Generator Reload Register 0000h
S0CON b FFB0h D8h Serial Channel 0 Control Register 0000h
S0EIC b FF70h B8h Serial Channel 0 Error Interrupt Control Register - - 00h
S0RBUF FEB2h 59h Serial Channel 0 Receive Buffer Register (read only) - xxxh
S0RIC b FF6Eh B7h Serial Channel 0 Receive Interrupt Control Register - - 00h
S0TBIC b F19Ch E CEh Serial Channel 0 Transmit Buffer Interrupt Control Reg. - - 00h
S0TBUF FEB0h 58h Serial Channel 0 Transmit Buffer Register (write only) 0000h
S0TIC b FF6Ch B6h Serial Channel 0 Transmit Interrupt Control Register - - 00h
SP FE12h 09h CPU System Stack Pointer Register FC00h
SSCBR F0B4h E 5Ah SSC Baud Rate Register 0000h
SSCCON b FFB2h D9h SSC Control Register 0000h
SSCEIC b FF76h BBh SSC Error Interrupt Control Register - - 00h
SSCRB F0B2h E 59h SSC Receive Buffer (read only) xxxxh
SSCRIC b FF74h BAh SSC Receive Interrupt Control Register - - 00h
SSCTB F0B0h E 58h SSC Transmit Buffer (write only) 0000h
Table 70. Special function registers ordered by name (continued)
Name
Physical
address
8-bit
address
Description
Reset
value
