Command Reference Web Authentication Commands
no web-auth portal
To be compatible with the old command, the device also supports the following hidden command:
web-auth portal-type { v1 | v2 portal-name }
Parameter
Description
Parameter Description
eportalv1
Ruijie first-generation web authentication
eportalv2
Ruijie second-generation web authentication
iportal
Ruijie built-in portal auth
portal-name
Name of Portal Server. The portal-name must have been created
using the portal-server command.
Defaults
First-generation web authentication
Command
mode
Global configuration mode and WLAN security configuration mode.
Usage Guide Both the portal and portal-type keywords can be applied to the portal server, but portal-type
keyword is not recommended and will be abandoned gradually.
At most, five commands can be configured in the WLAN security configuration mode. Portal-name
must be created using the portal-server command, and it is required that every portal-name is
different. The system will choose the first configured portal-name as the master authentication server
and followings as back-ups by priority. The priority level decreases based on the configuration
sequence.
If this command is configured in the WLAN safe configuration mode, the global commands will not
take effect in the WLAN security configuration.
Configuration
Examples
#Enable Ruijie second-generation web authentication, configure the name of Portal Server as
"edu-portal" and specify this server as the Portal Server for WLAN 100.
Ruijie# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Ruijie(config)#portal-server edu-portal ip 172.20.1.1 url
http://172.20.1.1:7080/index.php
Ruijie(config)# wlansec 100
Ruijie(wlansec)# web-auth portal edu-portal
Related
Commands
Command Description
portal-server
Creates the information about the Portal Server
for the second-generation web authentication.
Platform
Description
This command is supported only on wireless products.
