C interface
BTF
Byte transfer finished
This bit is set by hardware as soon as a byte is correctly received or transmitted with
interrupt generation if ITE = 1. It is cleared by software reading I2CSR1 register
followed by a read or write of I2CDR register. It is also cleared by hardware when
the interface is disabled (PE = 0).
– Following a byte transmission, this bit is set after reception of the acknowledge
clock pulse. In case an address byte is sent, this bit is set only after the EV6 event
(see Figure 170). BTF is cleared by writing the next byte in I2CDR register.
– Following a byte reception, this bit is set after transmission of the acknowledge
clock pulse if ACK = 1. BTF is cleared the byte from I2CDR register.
The SCL line is held low while BTF = 1.
‘0’: Byte transfer not done
‘1’: Byte transfer succeeded
BUSY
Bus busy
This bit is set by hardware on detection of a Start condition and cleared by hardware
on detection of a Stop condition. It indicates a communication in progress on the
bus. This information is still updated when the interface is disabled (PE
= 0).
‘0’: No communication on the bus
‘1’: Communication ongoing on the bus
TRA
Transmitter/Receiver
When BTF is set, TRA
= 1 if a data byte has been transmitted. It is cleared
automatically when BTF is cleared. It is also cleared by hardware after detection of
Stop condition (STOPF = 1), loss of bus arbitration (ARLO = 1) or when the
interface is disabled (PE
= 0).
‘0’: Data byte received (if BTF
= 1).
‘1’: Data byte transmitted.
ADD10
10-bit addressing in Master mode
This bit is set by hardware when the master has sent the first byte in 10-bit address
mode. It is cleared by software reading I2CSR1 register followed by a write in the
I2CDR register of the second address byte. It is also cleared by hardware when the
peripheral is disabled (PE
= 0).
‘0’: No ADD10 event occurred.
‘1’: Master has sent first address byte (header).
EVF
Event Flag
This bit is set by hardware as soon as an event occurs. It is cleared by software
reading I2CSR2 register in case of error event or as described in Figure 170. It is
also cleared by hardware when the interface is disabled (PE
= 0).
‘0’: No event
‘1’: One of the following events has occurred:
–BTF= 1 (Byte received or transmitted)
–ADSL
= 1 (Address matched in Slave mode while ACK = 1)
–SB= 1 (Start condition generated in Master mode)
–AF= 1 (No acknowledge received after byte transmission)
–STOPF
= 1 (Stop condition detected in Slave mode)
–ARLO= 1 (Arbitration lost in Master mode or misplaced data transition when SCL
is high)
– BERR
= 1 (Bus error, misplaced Start or Stop condition detected)
– ADD10 = 1 (Master has sent header byte)
– ENDAD
= 1 (Address byte successfully transmitted in Master mode)
