AudioCodes Mediant MSBR Series User Manual

Reference Guide 6. Show Commands
Version 7.2 117 Mediant MSBR
Command Description
L2TP is used to support VPNs and for ISP services
delivery.
loopback <ID>
Displays information about the Loopback interfaces,
according to interface ID. The MSBR's loopback
interface is logical and virtual rather than physical like the
Fast Ethernet interface or the Gigabit Ethernet interface.
pppoe <ID>
Displays information about Point-to-Point Protocol over
Ethernet (PPPoE) tunnel interfaces, according to
interface ID.
pptp <ID>
Displays information about Point-to-Point Tunneling
Protocol (PPTP) interfaces, according to interface ID.
rates {refreshing}
Displays information about the interfaces rates.
 To stop the refreshing (if you choose the
refreshing
option): Press Ctrl+C.
status
Displays the interface line statuses.
switchport {rates
<refreshing>}
Displays information about the switchport interface.
 rates (Displays interface switchport data rates)
 To stop the refreshing (if you choose the
refreshing
option): Press Ctrl+C.
shdsl
SHDSL
vlan <ID>
Displays information about the VLAN interfaces,
according to interface ID.
vti <ID>
Displays information about the Virtual Tunnel Interfaces
(VTIs), according to interface ID.
Command Mode
Basic User and Privileged User
Note
This command is applicable only to data-router functionality.
Example
This example displays interface line status:
show data interfaces status
Port Description Status Vlan Duplex Speed
FastEthernet 1/1 disconnected trunk - -
FastEthernet 1/2 disconnected trunk - -
FastEthernet 1/3 disconnected trunk - -
FastEthernet 1/4 disconnected trunk - -
GigabitEthernet 0/0 WAN Copper connected - FULL 1Gbps
Fiber 0/1 WAN Fiber disconnected - - -
