AudioCodes Mediant MSBR Series User Manual

Version 7.2 353 Mediant MSBR
Reference Guide 59. gateway
59 gateway
This command configures the gateway and includes the following subcommands:
 advanced (see Section 59.1)
 analog (see Section 59.2)
 digital (see Section 59.3)
 dtmf-supp-service (see Section 59.4)
 manipulation (see Section 59.5)
 routing (see Section 59.6)
 settings (see Section 59.7)
 trunk-group (see Section 59.8)
 trunk-group-setting (see Section 59.9)
 voice-mail-setting (see Section 59.10)
59.1 advanced
This command configures advanced gateway parameters.
Syntax
(config-voip)# gateway advanced
(gw-settings)#
Command Description
enable-rai {off|on}
Enables generation of an RAI (Resource Available
Indication) alarm if the device's busy endpoints exceed a
user-defined threshold.
forking-timeout
Configures the timeout (in seconds) that is st
arted after the
first SIP 2xx response has been received for a User Agent
when a Proxy server performs call forking (Proxy server
forwards the INVITE to multiple SIP User Agents).
reans-info-enbl
{off|on}
Enables the device to send a SIP INFO message with the
On-Hook/Off-Hook parameter when the FXS phone goes
on-hook during an ongoing call and then off-hook again,
within the user-defined regret timeout.
tel2ip-no-ans-timeout
Configures
the time (in seconds) that the device waits for a
200 OK response from the called party (IP side) after
sending an INVITE message, for Tel-to-IP calls.
time-b4-reordr-tn
Configures the delay interval (in seconds) from when the
device receives a SIP BYE message (i.e., remote party
terminates call) until the device starts playing a reorder
tone to the FXS phone.
Command Mode
Privileged User
