AudioCodes Mediant MSBR Series User Manual

Reference Guide 5. Debug Commands
Version 7.2 55 Mediant MSBR
Examples
The debug capture is de-activated using the following existing commands:
# debug capture data physical stop 192.168.0.3 vrf vrf1
Trying to send capture to TFTP/FTP server , filename debug-
capture-data-16032014-154400
Finished
5.6.1.5 debug capture data physical insert-pad
This command makes a manual mark in the captured file.
Syntax
debug capture data physical insert-pad
Default
By default, capture is inactive.
Command Mode
Enable
Related Commands
NA
Examples
The following example inserts a manual mark in the captured file.
# debug capture data physical insert-pad
5.6.1.6 debug capture data physical target
This command defines the destination server for the captured packet file.
Syntax
debug capture data physical target ftp user <ftp username>
password <ftp password>
debug capture data physical target tftp
debug capture data physical target usb
Arguments Description
ftp Defines using an FTP server.
tftp Sends the capture to a TFTP server.

AudioCodes Mediant MSBR Series Specifications

General

Product Series	Mediant MSBR Series
Category	Network Router
VoIP Protocols	SIP, H.323
Fax Support	T.38, G.711 pass-through
Integrated Firewall	Yes
VPN Support	IPSec, L2TP, PPTP
Management	Web GUI, CLI, SNMP, TR-069
FXS Ports	Up to 8
FXO Ports	Up to 2
Voice Codecs	G.711, G.729, G.723.1
Router Features	NAT, DHCP, QoS
Security Features	Firewall, DoS protection
Redundancy	Optional
Dimensions	1U Rack Mountable
Operating Temperature	0°C to 40°C
Storage Temperature	-20 to 70 °C
Humidity	Up to 95% non-condensing
