75.1.2 IPv6 Static Routes Commands
The following describes IPV6 Static Routes commands.
75.1.2.1 ipv6 route
This command provides support for configuring IPv6 static routes (destination prefix).
Syntax
ipv6 route vrf <VRF anme> <IPv6 destination address>/<prefix>
<IPv6 gateway address> <interface name> <interface ID> [<metric
value>] [track <track ID>] [description <string>]
ipv6 route <IPv6 destination address>/<prefix> [<next hop>]
<interface name> <interface ID> [<metric value>] [track <track
ID>] [description <string>]
This syntax describes a route that depends also on the source prefix of the packets:
Ipv6 route [vrf <VRF name>] source <IP source prefix>|local-voip
destination <IP destination prefix> [<next hop>] <interface type>
<interface ID> [<metric value>] [track <track ID>] [output-vrf
<name>] [description <string>]
Command Description
VRF Name Defines the vrf name.
IPv6 source prefix or local-
voip
Defines the IP source prefix as X:X::X:X/M
MSBR in single network mode can also be set with local-
voip to define the route source address to all VoIP packets
generated locally by the MSBR
IPv6 destination prefix Defines an IPv6 prfix as X:X::X:X/M.
next hop Defines the next hop for routing
metric value Defines the priority (0 - 255) of the route in the routing
table. The smaller the value, the higher the priority of the
route.
track id
Defines the option to make the route dependable on the
configured track. (1-100)
output-vrf Defines the outout vrf, for route leaking between vrfs.
description Defines a route description.
Interface Type (ifname) Interface ID
gigabitethernet GigabitEthernet interface slot
and port (VLAN ID is optional)
[SLOT/PORT.VLANID]
cellular Cellular interface ID 0/0
gre Tunnel GRE ID [1-255]
ipip Tunnel IPIP ID [1-255]
l2tp L2TP ID [0-99]
