AudioCodes Mediant MSBR Series User Manual

Version 7.2 393 Mediant MSBR
Reference Guide 59. gateway
Example
This example configures a routing rule that routes calls from IP Group "ITSP" to Trunk Group
1:
(config-voip)# gateway routing ip2tel-routing 0
(ip2tel-routing-0)# name PSTN-to-ITSP
(ip2tel-routing-0)# src-ip-group-name ITSP
(ip2tel-routing-0)# trunk-group-id 1
(ip2tel-routing-0)# activate
59.6.6 settings
This command configures gateway routing parameter.
Syntax
(config-voip)# gateway routing settings
(gw-routing-settings)#
Command Description
alt-routing-tel2ip
Enables Alternative Routing Tel to IP.
alt-rte-tel2ip-keep-
alive
Time interval between OPTIONS Keep-Alive messages
for IP connectivity (seconds).
alt-rte-tel2ip-method
Tel to IP Alternative Routing Connectivity Method.
alt-rte-tel2ip-mode
Methods used for Alternative Routing operation.
alt-rte-tone-duration
Alternative Routing Tone Duration (milliseconds).
empty-dst-w-bch-nb
Replace empty destination number (received from Tel
side) with port number.
gw-routing-server
Enables Gateway Routing Server.
ip-dial-plan-name
Assigns a Dial Plan (by name) for tag-based IP-to-Tel
routing rules.
ip-to-tel-tagging-dst
IP-to-Tel Tagging Destination Dial Plan Index.
ip-to-tel-tagging-src
IP-to-Tel Tagging Source Dial Plan Index.
ip2tel-rmv-rte-tbl
Remove prefix defined in IP to Trunk Group table (IP-to-
Tel calls).
ip2tel-rte-mode
Defines order between routing incoming calls from IP side
and performing manipulations.
mx-all-dly-4-alt-rte
The maximum delay that will not prevent normal routing
(msec).
mx-pkt-loss-4-alt-rte
The maximum percentage of packet loss that will not
prevent normal routing.
npi-n-ton-to-cld-nb
Add NPI and TON as prefix to called number.
npi-n-ton-to-cng-nb
Add NPI and TON as prefix to calling number.
