AudioCodes Mediant MSBR Series User Manual

Reference Guide 5. Debug Commands
Version 7.2 65 Mediant MSBR
Command Mode
Privileged User
Note
The command is applicable only to the data-router functionality.
Example
This example configures sending data networking debugging messages to Syslog:
# debug data-syslog
5.10 debug debug-recording
This command enables debug recording. To collect debug recording packets, use Wireshark
open-source packet capturing program. AudioCodes' proprietary plug-in files are required.
They can be downloaded from https://www.audiocodes.com/library/firmware. Once
downloaded, copy the plug-in files to the directory in which you installed Wireshark, as
follows:
 ...\dtds\cdr.dtd: Wireshark\dtds\
 ...\plugins\<Wireshark ver.>\*.dll: Wireshark\plugins\<Wireshark ver.>
 ...\tpncp\tpncp.dat: Wireshark\tpncp
After starting Wireshark, type acdr in the 'Filter' field to view the debug recording messages.
Note that the source IP address of the messages is always the device's OAMP IP address.
Syntax
# debug debug-recording <Destination IP Address> {ip-
trace|port|pstn-trace|signaling|signaling-media|signaling-media-
pcm}
# debug debug-recording status
Command Description
Destination IP Address Configures the destination IP address (IPv4) to which to send
the debug recording (i.e., debug recording server).
ip-trace
Configures the debug recording filter type.
Filters debug
recording for IP network traces, using Wireshark-like
expression (e.g., udp && ip.addr==10.8.6.55). IP traces are
used to record any IP stream according to destination and/or
source IP address, or port and Layer-4 protocol (UDP, TCP or
any other IP type as defined by http://www.iana.com).
Network traces are typically used to record HTTP.
port
Configures the port of the debug recording server to which to
send the debug recording.
pstn-trace
Configures the debug recording capture type as PSTN trace.
The debug recording includes ISDN and CAS traces.
signaling
Configures the debug recording capture type as signaling.
The debug recording includes signaling information such as
