AudioCodes Mediant MSBR Series User Manual

Reference Guide 6. Show Commands
Version 7.2 167 Mediant MSBR
UnAvailableSeconds: 470 PathCodingViolation: 0
LineErroredSeconds: 0 SeverelyErroredSeconds: 0
SeverelyErroredFramingSeconds: 0
basic configuration:
framing: T1_FRAMING_ESF_CRC6
line-code: B8ZS
clock-master: CLOCK_MASTER_OFF
clock-priority: 0
trace-level: no-trace
6.12.9 show voip ip-group
This command displays the following QoS metrics per IP Group:
 QoE profile metrics per IP Group and its associated Media Realm on currently
established calls such as MOS, jitter, packet loss, and delay. Metrics are displayed as
average amounts.
 Bandwidth Profile (BW) metrics for Tx and Rx traffic per IP Group and/or Media Realm.
Metrics are displayed with a status color for each specific port.
 QoE profile metrics for the remote (far-end) such as MOS, jitter, packet loss, and
delay. Each metric is displayed with a specific color.
 Group MSA metrics for the IP Group and the Media Realm. Metrics are displayed as
an aggregated value.
Syntax
show voip ip-group <IP Groups Table Index> media-statistics
Command Mode
Basic User and Privileged User
Example
Displaying QoS metrics of IP Group configured in row index 0:
show voip ip-group 0 media-statistics
IPGroup 0. BWProfile: -1, QoEProfile: -1
--------------------------------------
MSA: 0
Averages: MOS 0 Remote MOS 0 Delay 0 Remote Delay 0 Jitter 0
Remote Jitter 0
Fraction loss tx 0 Fraction loss rx 0
Packet sent 0 Packet received 0
Audio Tx BW 0, Audio Tx Status Green
Audio Rx BW 0, Audio Rx Status Green
Total Tx BW 0, Total Tx Status Green
Total Rx BW 0, Total Rx Status Green
Video Tx BW 0, Video Tx Status Green
Video Rx BW 0, Video Rx Status Green
MSA color Gray MSA remote color Gray
MOS color Gray remote MOS color Gray
