AudioCodes Mediant MSBR Series User Manual

Reference Guide 56 Document #: LTRT-17939
Mediant MSBR
Arguments Description
usb Saves the capture to USB storage.
Default
By default, capture is inactive.
Note:
The usb option is only applicable when a USB stick is connected to the device. This applies
only to Mediant 5xx and Mediant 8xx devices.
Command Mode
Enable
Related Commands
NA
Examples
The following example sets the destination for the captured packet file as a TFTP server.
# debug capture data physical target tftp
5.6.1.7 debug capture data physical autostop
This command provides support for starting a debug-traffic capture on the device's physical
network interfaces and allowing it to run until a user-defined event. This event can be a Syslog
message or an interface state-change.
All physical targets (TFTP, FTP, and USB), and SSH retrieval are supported, as well as
regular and cyclic-buffer modes. When combined with cyclic-buffer mode, this command
makes diagnosis of network problems easier.
Syntax
debug capture data physical auto-stop {event|keep|send} syslog
<message>
debug capture data physical auto-stop event state-change
<interface>
debug capture data physical auto-stop event state-change any
debug capture data physical auto-stop {send <IP address>|keep}
no debug capture data physical auto-stop
Arguments Description
auto-stop Enables auto-stop capture on predefined events.
• event – Selects events
• keep – Keeps capture for SSH retrieval
•
send - Sends capture to the TFTP/FTP server
