AudioCodes Mediant MSBR Series User Manual

Reference Guide 5. Debug Commands
Version 7.2 57 Mediant MSBR
Arguments Description
<interface> Use one of the following:
• eth-lan
• eth-wan
• cellular-wan
• shdsl-wan
• t1-wan
• dsl-wan
depending on the hardware capabilities of the device.
This command may be issued multiple times to capture
data from several interfaces at once.
Default
By default, capture is inactive.
Note:
This command is applicable to Mediant MSBR.
Command Mode
Enable
Related Commands
NA
Examples:
The following are examples of how this command can be used.
 Defines the Syslog message event, upon which the device stops the debug capture:
# debug capture data physical auto-stop event syslog
"<message>"
 Defines the state change on a specific interface, upon which the device stops the
debug capture:
# debug capture data physical auto-stop event state-change
<interface, e.g., GigabitEthernet 0/0>
 Defines a state change on any interface, upon which the device stops the debug
capture:
# debug capture data physical auto-stop event state-change any
 Defines what to do with the debug capture when it is automatically stopped:
# debug capture data physical auto-stop {send <IP
address>|keep}
Where:
send sends the capture to the defined IP address
keep saves the capture on the device for later retrieval
 Disables the automatic stopping feature for debug captures:
# no debug capture data physical auto-stop
