AudioCodes Mediant MSBR Series User Manual

Reference Guide 54 Document #: LTRT-17939
Mediant MSBR
sent to a PC via TFTP/FTP. Please make sure that
VLAN 1 is defined and the PC is accessible through it.
5.6.1.4 debug capture data physical stop vrf
This command stops capturing files.
Syntax
debug capture data physical stop server-ip vrf <vrf name>
Arguments Description
server-ip Defines the IP address of the TFTP/FTP server.
vrf name Defines the VRF name.
Default
By default, capture is inactive.
Note:
 The captured data is collected locally, and only then sent to the PC later on.
 The usb option is only applicable when a USB stick is connected to the device. This
applies only to Mediant 5xx and Mediant 8xx devices.
 Once the start command is issued, recording is performed to an in-memory buffer. If
the buffer becomes full, recording stops.
 The stop command creates a file named debug-capture-data-
<timestamp>.pcap and sends it to the TFTP server. The TFTP server must be
configured to allow file uploads.
 The generated PCAP file is in the Extensible Record Format (ERF); recent versions of
Wireshark (1.5.0 or newer) are recommended for proper dissection.
 Wireshark's ERF settings must be configured as follows:
Command Mode
Enable
Related Commands
NA
