AudioCodes Mediant MSBR Series User Manual

Reference Guide 8. General Root Commands
Version 7.2 199 Mediant MSBR
Command Description

gigabitethernet (Gigabit Ethernet interface)
 gre (GRE tunnel interface)
 ipip (IPIP tunnel interface)
 ipipv6 (IPIPv6 tunnel interface)
 ipv6ip (IPv6IP tunnel interface
 l2tp (L2TP tunnel interface)
 loopback (PPPoE interface)
 pppoe (PPPoE interface)
 pptp (PPTP tunnel interface)
 vlan (VLAN interface)
vti (VTI tunnel interface)
source data vrf
(Optional) Specifies the VRF name from where you want to
send the ping packet.
summarized
Displays a summary of the ping results.
Command Mode
Privileged User
Example
 Sending 3 ICMP packets with 555 bytes payload size to 10.4.0.1 via interface VLAN 1:
ping 10.4.0.1 source data interface vlan 1 repeat 3 size 555
PING 10.4.0.1 (10.4.0.1): 555 data bytes
563 bytes from 10.4.0.1: icmp_seq=0 ttl=255 time=1.3 ms
563 bytes from 10.4.0.1: icmp_seq=1 ttl=255 time=1.1 ms
563 bytes from 10.4.0.1: icmp_seq=2 ttl=255 time=1.2 ms
--- 10.4.0.1 ping statistics ---
3 packets transmitted, 3 packets received, 0 packet loss
round-trip min/avg/max = 1.1/1.2/1.3 ms
 Pinging an FQDN:
ping corp.abc.com source voip interface vlan 1
 Pinging an IPv6 destination address:
ping ipv6 2001:15::300
