AudioCodes Mediant MSBR Series User Manual

Version 7.2 397 Mediant MSBR
Reference Guide 59. gateway
Command Description
channel-select-mode
{always-
ascending|always-
descending|channel-
cyclic-
ascending|cyclic-
descending|dst-number-
ascending|dst-number-
cyclic-ascending|dst-
phone-number|not-
configured|ring-to-
hunt-group|select-
trunk-by-supp-serv-
table|src-phone-
number|trunk-channel-
cyclic-
ascending|trunk-
cyclic-ascending}
Defines the method by which IP-to-Tel calls are assigned
to the channels of the Trunk Group.
contact-user
Defines the user part for the SIP Contact URI in INVITE
messages, and the From, To, and Contact headers in
REGISTER requests.
gateway-name
Defines the host name for the SIP From header in INVITE
messages, and the From and To headers in REGISTER
requests.
mwi-interrogation-type
{none|not-
configured|result-not-
used|use-activate-
only|use-result}
Defines message waiting indication (MWI) QSIG-to-IP
interworking for interrogating MWI supplementary services.
registration-mode
{dont-register|not-
configured|per-
account|per-
endpoint|per-gateway}
Defines the registration method of the Trunk Group.
serving-ip-group-name
Assigns an IP Group to where the <device> sends INVITE
messages for calls received from the Trunk Group.
trunk-group-id
Defines the Trunk Group ID that you want to configure.
trunk-group-name
Defines a descriptive name, which is used when
associating the row in other tables.
used-by-routing-server
{not-used|used}
Enables the use of the Trunk Group by a routin
g server for
routing decisions.
Command Mode
Privileged User
Example
This example configures channel select method to ascending for Trunk Group 1:
(config-voip)# gateway gateway trunk-group-setting 0
