AudioCodes Mediant MSBR Series User Manual

Reference Guide 410 Document #: LTRT-17939
Mediant MSBR
Command Description
fxs-tx-gain-control
Defines gain\attenuation of the FXS Tx path between -
22db and 10db.
metering-on-time
Defines the metering signal duration to be detected
metering-type
Defines the metering method for charging pulses.
min-flash-hook-time
Defines the minimal time (in msec) for detection of a flash
hook event (for FXS only).
mwi-indication-type
Defines the type of (MWI) Message Waiting Indicator (for
FXS only).
polarity-reversal-type
Defines type of polarity reversal signal used for network
far-end answer and disconnect indications.
rx-gain-control
Defines gain attenuation of the FXO Rx path between -
15db and 12db.
time-to-sample-analog-
line-voltage
Defines the time to sample the analog line voltage after
offhook, for the current disconnect threshold.
tx-gain-control
Defines gain attenuation of the FXO Tx path between -
15db and 12db.
wink-time
Defines time elapsed between two consecutive polarity
reversals.
Command Mode
Privileged User
Example
This example enables FXS port 1 in Module 2:
(config-voip)# interface fxs-fxo
(fxs-fxo)# analog-port-enable 1/2
(fxs-fxo)# activate
