AudioCodes Mediant MSBR Series

Version 7.2 413 Mediant MSBR
Reference Guide 62. ip-group
Command Description
src-uri-input
Defines the SIP header in the incoming INVITE that is
used for call matching characteristics based on source
URIs.
srd-name
Assigns an SRD to the IP Group.
tags
Assigns a Dial Plan tag used for routing and/or
manipulation.
topology-location
{down|up}
Defines the display location of the IP Group in the
Topology view of the Web interface.
type
{gateway|server|user}
Defines the type of IP Group
use-requri-port
{disable|enable}
Enables the <device> to use the port indicated in the
Request-URI of the incoming message as the destination
port when routing the message to the IP Group.
used-by-routing-server
{not-used|used}
Enables the IP Group to be used by a third-party routing
server for call routing decisions.
username
Defines the shared username for authenticating the IP
Group, when the <device> acts as an Authentication
server.
uui-format
{disable|enable}
Enables the
generation of the Avaya UCID value, adding it
to the outgoing INVITE sent to this IP Group.
Command Mode
Privileged User
Example
This example configures a Server-type IP Group called "ITSP":
(config-voip)# ip-group 0
(ip-group-0)# name ITSP
(ip-group-0)# type server
(ip-group-0)# media-realm-name ITSP
(ip-group-0)# activate
